Danfoss 060G6763 MBS 3000 Pressure Transmitter

Only 10 item(s) left in stock

Manufacturer: Danfoss
Product No.: 060G6763
Country of origin:United States
Product Type: Pressure Transmitters
Payment: T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months

Description

The Danfoss 060G6763 is a high-performance MBS 3000 pressure transmitter designed for use in harsh industrial environments. This compact pressure transmitter is engineered to provide reliable and accurate pressure measurement for a wide range of applications, including hydraulic systems, pump control, and process monitoring. The device features a rugged design, ensuring long-term stability and resistance to shock and vibration.

Operating with a standard industrial current output signal (4–20 mA), the 060G6763 integrates seamlessly into PLC and DCS control systems. It is built to withstand demanding ambient conditions, with an operating temperature range of -40 Celsius to 85 Celsius and an IP65-rated enclosure, providing robust protection against dust and water jets.

Features

Robust design for industrial pressure measurement
Measuring range: -1 to 15 bar (-14.5 to 217.5 psi)
Reliable 4-20 mA current output signal
Wide supply voltage range: 9.00 V DC to 32.00 V DC
IP65 ingress protection rating
Compact form factor with EN 175301-803-A angular electrical connection
High resistance to shock and vibration

Applications

Hydraulic and pneumatic systems
Compressor and pump monitoring
Process plant automation
HVAC and cooling systems
General industrial machinery

Technical Specifications

Feature	Specification
Manufacturer	Danfoss
Model	060G6763
Series	MBS 3000
Pressure Range	-1 to 15 bar (-14.5 to 217.5 psi)
Output Signal	4–20 mA
Supply Voltage	9.00 to 32.00 V DC
Electrical Connection	Angular connector (EN 175301-803-A)
Enclosure Rating	IP65
Ambient Temperature	-40 to 85 Celsius
Weight	0.125 kg
Shipping Weight	1.5 kg

Connections/Interfaces

Connector Pin	Function
Pin 1	Supply Voltage +
Pin 2	Output Signal (4-20 mA)
Ground	Case/Shield

Installation Guidelines

Mounting: Install the transmitter in a location that minimizes liquid hammer and pressure surges.
Orientation: For liquid applications, mount the sensor with the pressure connection facing downward to prevent air entrapment.
Wiring: Use shielded cable for the 4-20 mA loop to mitigate electromagnetic interference (EMI). Ensure the EN 175301-803-A connector is fully tightened to maintain the IP65 seal.
Power Supply: Ensure the supply voltage remains within the 9.00–32.00 V DC range to avoid signal inaccuracies or damage to the internal electronics.
Environment: Avoid mounting the device in locations exceeding the maximum ambient temperature of 85 Celsius.

Key Features:

#Danfoss #Pressure Transmitters

What is the output signal range for the 060G6763?

The device outputs a standard 4-20 mA current signal.

What is the operating pressure range of this transmitter?

The measuring range is -1 to 15 bar (-14.5 to 217.5 psi).

What type of electrical connector does this model use?

It uses an angular connector compliant with the EN 175301-803-A standard.

What is the required supply voltage for this unit?

The supply voltage must be between 9.00 V DC and 32.00 V DC.
