HG-JR353

Mitsubishi Electric

Mitsubishi Electric HG-JR353 HG-JR Series AC Servo Motor

SKU HG-JR353

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: HG-JR353
  • Origin United States
  • Product Type: AC Servo Motors
  • Payment: T/T, Western Union
  • Weight: 14.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

AC Servo Motors HG-JR Series
Quantity
Call sales Contact

Product Description

Description

Optimized for high-performance motion control, the HG-JR353 is a high-capacity rotary high-inertia AC servo motor engineered for the Mitsubishi Electric MELSERVO-J4 platform. This motor is purpose-built to handle applications characterized by high load inertia or fluctuating torque requirements. By delivering precise speed control, high torque density, and rapid acceleration capabilities, the unit ensures stable machinery operation under challenging mechanical conditions.

The motor integrates seamlessly with compatible MELSERVO MR-J4 servo amplifiers to form a closed-loop positioning system. This integration allows for real-time monitoring, high-resolution feedback, and minimized settling times, making the HG-JR353 an ideal component for machinery requiring strict synchronization and dynamic performance.

Features

  • High-Inertia Design: Provides superior stability and control when handling high or fluctuating load inertia.
  • Optimized Resolution: Built-in high-resolution encoder support ensures exceptional positioning accuracy and smooth rotational velocity.
  • Industrial-Grade Enclosure: Sealed structure provides ingress protection against moisture, dust, and non-corrosive liquids.
  • Low Maintenance: Brushless design reduces mechanical wear and operational downtime in long-duration duty cycles.

Applications

  • Heavy-duty material handling and conveying systems.
  • Multi-axis robotic arms and articulated manipulators.
  • High-speed packaging and cartoning machinery.
  • Metal processing and high-precision machine tool axes.
  • Textile machinery and winding systems.

Technical Specifications

Manufacturer Mitsubishi Electric
Model / Part Number HG-JR353
Series HG-JR (MELSERVO-J4 Series)
Rated Output 3.5 kW
Rated Speed 3000 r/min
Maximum Speed 6000 r/min
Rated Current 17 A
Maximum Current 51 A
Power Supply / Voltage Class 200 V AC Class
Enclosure Rating IP67 (excluding shaft pass-through)
Approximate Weight 14 kg

Installation Guidelines

  • Coupling and Alignment: Ensure precise alignment between the motor shaft and the driven load. Excessive radial or axial loads on the shaft will cause premature bearing failure.
  • Heat Dissipation: Install the motor in a well-ventilated area. Keep the surrounding ambient temperature between 0 and 40 Celsius to prevent thermal shutdowns.
  • Cabling and Shielding: Use official Mitsubishi Electric motor power and encoder cables. Ground the motor frame properly to reduce electromagnetic interference (EMI) and ensure signal integrity.

Compliance and Certifications

  • CE Marked
  • UL Recognized
  • cUL Listed
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the rated output and current of the HG-JR353 servo motor?
The HG-JR353 AC servo motor has a rated output of 3.5 kW and a rated current of 17 A.
What is the maximum rotational speed of this motor?
While the motor has a rated speed of 3000 r/min, it can achieve a maximum rotational speed of up to 6000 r/min.
What ingress protection rating does the HG-JR353 feature?
The motor enclosure is IP67 rated, excluding the shaft pass-through, which provides high resistance to dust and water ingress.
Which drive series is compatible with this motor?
The HG-JR353 is designed to be paired with Mitsubishi Electric MELSERVO-J4 series servo amplifiers.
