Mitsubishi Electric HG-SR202BJ HG-SR Series AC Servo Motor

Description

Designed for high-performance industrial motion control, the Mitsubishi Electric HG-SR202BJ operates as a medium-inertia AC servo motor within the MELSERVO-J4 rotary motor family. This unit features a robust physical build optimized for precise torque and speed regulation in automated machinery. It comes integrated with a built-in electromagnetic brake and an oil seal, making it highly reliable for heavy-duty positioning systems that require holding torque and environmental protection.

Features

• Medium-inertia rotor design providing stable speed and torque regulation.
• Integrated electromagnetic brake for secure holding capability during power-off states.
• Built-in oil seal to prevent fluid ingress and protect internal motor components.
• Class 155 (F) insulation rating for enhanced thermal endurance during continuous operation.
• V10 vibration rank ensuring low structural vibration and high operational stability.

Applications

• Material handling systems and transfer lines.
• Packaging and labeling machinery.
• Robotic gantry systems and linear actuators.
• Textile processing and tension control machinery.

Technical Specifications

Installation Guidelines

• Ensure the motor shaft is precisely aligned with the load to prevent premature bearing wear and mechanical fatigue.
• Mount the unit in an indoor environment shielded from direct sunlight, corrosive gases, and high concentrations of conductive dust.
• Provide sufficient ventilation space around the motor housing to facilitate heat dissipation.
• Ground the motor frame securely to the control panel earth ground to minimize electrical noise and ensure safety.
