Mitsubishi Electric MR-J2S-60A-S004 MELSERVO-J2-Super AC Servo Drive

SKU MR-J2S-60A-S004

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: MR-J2S-60A-S004
Country of origin:United States
Product Type: AC Servo Drives
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

Description

Engineered for high-precision motion control, the MR-J2S-60A-S004 AC servo amplifier is part of the established Mitsubishi Electric MELSERVO-J2-Super product family. Designed to deliver stable speed and torque regulation, this drive provides industrial automation systems with reliable closed-loop control. The unit interfaces seamlessly with compatible HC-series servo motors, making it a critical component for demanding positioning tasks.

The MR-J2S-60A-S004 features a general-purpose interface supporting both analog input and pulse train command signals. The "S004" designation indicates a manufacturer-specific variant configured for specialized application environments or specific default parameter baselines. This model integrates digital tuning algorithms to minimize positioning settling time and suppress mechanical resonance.

Features

Real-time auto-tuning functionality that continuously adjusts control gains to match the load inertia.
Advanced machine resonance suppression filters to minimize high-frequency mechanical vibrations.
Dual-interface control supporting both analog voltage commands and high-speed pulse train inputs.
Built-in RS-232C and RS-422 serial communication interfaces for parameter configuration and diagnostic monitoring.
Comprehensive protective features including overcurrent, overvoltage, regenerative error, and overload monitoring.

Applications

Packaging machinery and automated wrapping stations.
Semiconductor fabrication and wafer handling systems.
Textile machinery requiring high-precision synchronization.
Multi-axis pick-and-place industrial robotic arms.
Material handling systems and precision conveyors.

Technical Specifications

Manufacturer	Mitsubishi Electric
Model / Part Number	MR-J2S-60A-S004
Series	MELSERVO-J2-Super
Product Type	AC Servo Drive / Amplifier
Output Rated Power	600 W
Output Rated Current	3.2 A
Output Rated Voltage	3-Phase 170 VAC
Input Power Supply	3-Phase or 1-Phase 200 to 230 VAC, 50/60 Hz
Control System	Sinusoidal PWM control, current control system
Operating Ambient Temperature	0 to 55 degC
Storage Temperature	-20 to 65 degC
Ambient Humidity	Max 90% RH (non-condensing)
Cooling Method	Natural cooling (force cooling where applicable)

Connections and Interfaces

Connector / Terminal Symbol	Function Description
L1, L2, L3	Main power supply input terminals
U, V, W	Servo motor power output connections
CN1A / CN1B	I/O signal and daisy-chain communication connectors
CN2	Encoder feedback cable interface
CN3	Personal computer or parameter unit communication interface (RS-232C / RS-422)

Installation Guidelines

Ensure vertical mounting orientation on a flat panel to facilitate natural convective heat dissipation.
Maintain a minimum clearance of 80 mm above and below the drive, and at least 10 mm on both sides.
Verify that the installation enclosure is free from conductive dust, corrosive gases, and direct moisture.
Connect the ground terminal (PE) to a dedicated structural ground point using Class 3 grounding (100 ohms or less).
Always use shielded twisted-pair cables for encoder and control signals to prevent electromagnetic interference (EMI).

Compliance and Certifications

CE Mark (Low Voltage and EMC Directives)
UL Listed
cUL Certified

FAQ

What does the S004 suffix stand for in the MR-J2S-60A-S004 model number?

The S004 suffix represents a manufacturer-certified configuration or specialized parameter setting. While keeping the core specifications of the standard MR-J2S-60A intact, it is tailored for specific industrial systems.

Can the MR-J2S-60A-S004 be run on single-phase power?

Yes, this model can accept single-phase 200-230 VAC input power, though user applications must check for potential de-rating requirements depending on load conditions.

What is the rated power output of this drive?

The MR-J2S-60A-S004 has a rated power output of 600 W (0.6 kW) and a rated current output of 3.2 A.

Which software is used to configure and monitor this drive?

Mitsubishi Electric's MR Configurator (setup software) is used via the CN3 serial port to configure parameters, monitor diagnostics, and perform test operations.
