Omron CJ1W-TC103 SYSMAC CJ Series Temperature Control Module

SKU OMRON-CJ1W-TC103

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: OMRON-CJ1W-TC103
  • Origin Japan
  • Product Type: Temperature Control Modules
  • Payment: T/T, Western Union
  • Weight: 0.15 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

SYSMAC CJ Series Temperature Control Modules
Quantity
Call sales Contact

Product Description

Description

Executing precise thermal regulation within SYSMAC PLC architectures, the CJ1W-TC103 functions as a dedicated, multi-channel temperature control module. This unit interfaces directly with the CJ-series CPU bus to perform autonomous PID thermal control, significantly reducing CPU overhead while managing critical loops. Equipped with high-density thermocouple inputs and NPN transistor outputs, it serves as a reliable solution for closed-loop thermal management across diverse manufacturing environments.

Features

  • Four independent PID control loops with auto-tuning and self-tuning functions.
  • Direct thermocouple input supporting multiple standard sensor types.
  • Transistor outputs (NPN) designed for driving external solid-state relays (SSRs).
  • High-speed backplane data transfer compatible with CJ1, CJ2, and NJ/NX controller networks.
  • Run/Stop control and parameter configuration accessible directly through the PLC memory allocation.

Applications

  • Plastic extrusion and injection molding machinery.
  • Industrial heat treatment furnaces and curing ovens.
  • Packaging machines requiring precise sealing temperature control.
  • Semiconductor fabrication thermal processing chambers.

Technical Specifications

Manufacturer Omron
Part Number / Model CJ1W-TC103
Series SYSMAC CJ Series
Module Type Temperature Control Unit
Number of Control Loops 4 loops
Input Type Thermocouple (K, J, T, L, R, S, B, etc.)
Output Type NPN Transistor (pulse)
Control Method 2-PID control or ON/OFF control
Current Consumption 0.25 A max at 5V DC (from backplane)
Weight 150 g (approx. 5.29 oz)
Mounting Location CJ-series CPU Rack or Expansion Rack

Compliance and Certifications

  • CE compliant
  • UL and cULus listed
  • RoHS compliant
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Omron CJ1W-TC103 module?
The CJ1W-TC103 is a 4-loop temperature control module designed for the Omron SYSMAC CJ series PLC, utilizing thermocouple inputs and NPN transistor outputs to execute autonomous PID thermal control.
What sensor types are compatible with the CJ1W-TC103?
The module is designed for thermocouple inputs, supporting standard industrial types such as K, J, T, L, R, S, and B.
Does this module require an external power supply for control operations?
The internal control circuitry is powered directly from the CJ-series backplane (5V DC bus), drawing a maximum current of 0.25 A.
