Siemens 6AV7260-2DA20-0BA0 SIMATIC IPC677D Panel PC

SKU 6AV7260-2DA20-0BA0

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV7260-2DA20-0BA0
Country of origin:Germany
Product Type: PC Panel
Barcode: 85371098
Payment: T/T, Western Union
Weight: 17g
Dimensions: 60.00 x 56.50 x 30.00 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6AV7260-2DA20-0BA0 is a SIMATIC IPC677D Panel PC designed for industrial applications. This unit features a 22-inch touch display with a resolution of 1920x1080, powered by an Intel Core i3-4330TE processor. It includes multiple communication interfaces such as Gigabit Ethernet, USB V3.0, and a serial port (COM1). The IPC677D is equipped with a 500 GB SATA HDD, 4 GB DDR3 1600 DIMM RAM, and two PCI slots. Integrated features include a watchdog, temperature and fan monitoring, and an onboard RAID controller. The system comes pre-installed with Windows 7 Ultimate 64 Bit SP1 (MUI) and SIMATIC IPC DiagMonitor, utilizing an enclosed AC 110/230V industrial power supply unit with NAMUR compatibility.

Features

SIMATIC IPC677D Panel PC with 22-inch Touch Display (1920x1080)
Intel Core i3-4330TE CPU (2C/4T, 2.4 GHz, 4 MB Cache, VT-X)
500 GB SATA Hard Disk Drive
4 GB DDR3 1600 DIMM RAM
Dual 10/100/1000 Mbit/s Ethernet Ports
Four USB V3.0 Ports (plus front USB) and One Serial Port (COM1)
Integrated Watchdog, Temperature, and Fan Monitoring
Onboard RAID Controller
Two PCI Expansion Slots (without expansion hardware)
Pre-installed Windows 7 Ultimate 64 Bit SP1 (MUI)
Includes SIMATIC IPC DiagMonitor software
Enclosed AC 110/230V Industrial Power Supply Unit with NAMUR

Applications

The Siemens SIMATIC IPC677D Panel PC is suitable for a wide range of industrial automation and control applications, including:

Human-Machine Interface (HMI) for process visualization and operator control.
Data acquisition and processing in manufacturing environments.
Supervisory Control and Data Acquisition (SCADA) systems.
Machine control and monitoring in production lines.
Industrial workstation for engineering and maintenance tasks.

Technical Specifications

Brand	Siemens
Manufacturer	Siemens
Range	Simatic Panel PC
Subrange	IPC
Product Type	PC panels
PLM Product Phase	Phase-Out
Ethernet Ports	2x 10/100/1000 Mbit/s
USB Ports	4x USB V3.0 (plus front USB)
Serial Port	1x (COM1)
Display Type	22" Touch
Display Resolution	1920x1080
CPU	Intel Core i3-4330TE (2C/4T, 2.4 GHz, 4 MB Cache, VT-X)
Hard Drive	500 GB HDD SATA
RAM	4 GB DDR3 1600 DIMM
Expansion Slots	2x PCI (without expansion HW)
Operating System	Windows 7 Ultimate 64 Bit SP1, MUI (DE, EN, FR, ES, IT)
Monitoring	Watchdog, Temperature, Fan
RAID Controller	Onboard
Included Software	SIMATIC IPC DiagMonitor
Power Supply	AC 110/230V Industrial Power Supply Unit with NAMUR
Power Supply Cable	Europe
Package Dimensions (Calculated)	60.00 x 56.50 x 30.00 cm
Shipping Weight	17.00 kg
Commodity Code	85371098
Export Control Regulations (ECCN)	N

Connections / Interfaces

Interface Type	Quantity / Description
Ethernet	2x 10/100/1000 Mbit/s
USB	4x USB V3.0 (rear), 1x USB (front)
Serial	1x COM1
PCI	2x PCI slots
Power Input	AC 110/230V Industrial Power Supply

FAQ

What operating system is pre-installed on the 6AV7260-2DA20-0BA0?

The Panel PC comes with Windows 7 Ultimate 64 Bit SP1, including a Multi-User Interface (MUI) for German, English, French, Spanish, and Italian languages.

What are the primary communication interfaces available?

It features two 10/100/1000 Mbit/s Ethernet ports, four USB V3.0 ports (plus a front USB port), and one serial port (COM1).

Can the storage or memory be expanded?

The unit is equipped with a 500 GB SATA HDD and 4 GB DDR3 1600 DIMM RAM. It also includes two PCI expansion slots for additional hardware.

What type of power supply does this Panel PC use?

It uses an enclosed AC 110/230V industrial power supply unit with NAMUR compatibility, and includes a European power supply cable.

What is the function of the integrated monitoring features?

The Panel PC includes a watchdog, temperature monitoring, and fan monitoring to ensure system reliability and alert for potential operational issues.
