Siemens 6ES7214-1BD23-0XB8 SIMATIC S7-200 SMART CPU Module

SKU 6ES7214-1BD23-0XB8

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7214-1BD23-0XB8
Country of origin:Germany
Product Type: PLC CPU Modules
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 400g
Dimensions: 14 cm x 6.1 cm x 9.5 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6ES7214-1BD23-0XB8 is a compact CPU module within the SIMATIC S7-200 SMART series, engineered for basic industrial automation and control tasks. This unit integrates a versatile I/O set, including 14 digital inputs, 10 digital outputs, and 2 analog inputs, making it suitable for small-scale machinery and standalone applications. It features 12 KB of program memory and 8 KB of data memory to handle fundamental logic operations. An integrated Ethernet port provides essential connectivity for programming, monitoring, and networking in modern industrial environments.

Features

Integrated 14 Digital Inputs and 10 Digital Outputs
Includes 2 onboard Analog Inputs
12 KB Program Memory and 8 KB Data Memory
Built-in Ethernet port for network communication
Compatible with SIMATIC S7-200 SMART expansion modules
Compact design for space-constrained control panels

Applications

OEM machine building
Small manufacturing cells
Conveyor control systems
Building automation
Simple motion control tasks

Technical Specifications

Specification	Value
Manufacturer	Siemens
Part Number	6ES7214-1BD23-0XB8
Series	SIMATIC S7-200 SMART
Module Type	CPU Module
Digital Inputs	14
Digital Outputs	10
Analog Inputs	2
Program Memory	12 KB
Data Memory	8 KB
Communication Port	Ethernet
Shipping Weight	0.4 kg
HS Code	8537101190
Country of Origin	Germany
Package Dimensions (Calculated)	14 cm x 6.1 cm x 9.5 cm

Installation Guidelines

CRITICAL WARNING: Hazardous voltages are present in control cabinets. All installation and maintenance procedures must be performed by qualified personnel using appropriate personal protective equipment (PPE) and following local Lockout/Tagout (LOTO) safety regulations.

1
Ensure the control cabinet is completely de-energized and locked out before beginning installation. Verify the absence of voltage with a properly rated multimeter.
2
Securely mount the module onto a standard 35mm DIN rail inside the enclosure. Ensure adequate clearance for ventilation and wiring.
3
Connect the 24V DC power supply to the designated terminals. Verify correct polarity to prevent damage to the module.
4
Terminate all digital and analog I/O wiring at the module's terminal blocks. Use the correct wire gauge and ensure terminals are torqued to the manufacturer's specification. Route signal wires separately from high-voltage power cables.
5
Connect a shielded Ethernet cable to the module's port for network communication. Ensure the cable shield is properly terminated to a chassis ground.
6
Verify that the module and DIN rail have a low-impedance connection to the main panel's protective earth (PE) ground. After all connections are verified, remove the lockout and re-energize the panel for commissioning.

FAQ

What are the I/O counts for this Siemens CPU module?

The 6ES7214-1BD23-0XB8 features 14 digital inputs, 10 digital outputs, and 2 analog inputs integrated into the main unit.

What communication port is available on this module?

This module includes an integrated Ethernet port for network connectivity, programming, and HMI communication.

How much memory does the 6ES7214-1BD23-0XB8 have?

It is equipped with 12 KB of program memory and 8 KB of data memory, suitable for small-scale automation applications.

Is this PLC module expandable?

Yes, it is compatible with the SIMATIC S7-200 SMART series of expansion modules, allowing for additional I/O as application requirements grow.
