Siemens 6ES7647-8AG70-3HA1 SIMATIC IPC277D Nanobox PC

SKU 6ES7647-8AG70-3HA1

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7647-8AG70-3HA1
Country of origin:Germany
Product Type: Industrial PC
Barcode: 85371091
Payment: T/T, Western Union
Weight: 2450g
Dimensions: 22.0 x 10.0 x 18.0 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6ES7647-8AG70-3HA1 is a compact, fan-less Nanobox PC from the SIMATIC IPC277D series, designed for demanding automation tasks in space-constrained environments. This unit is powered by an Intel Atom E660 1.3 GHz processor and is equipped with 2 GB of RAM and an 8 GB CompactFlash card for storage. It comes pre-loaded with Windows Embedded Standard 7 SP1 and a comprehensive Siemens HMI software package, including WinCC Advanced RT V13 (2048 PowerTags) and a WinCC RT Advanced V14 license, making it ready for immediate deployment in visualization and control applications. The device offers extensive connectivity with dual Gigabit Ethernet ports, four high-current USB 2.0 ports, and an RS232 serial interface.

Features

Processor: Intel Atom E660 (1.3 GHz)
Memory: 2 GB RAM
Storage: 8 GB SIMATIC PC CompactFlash card
Operating System: Windows Embedded Standard 7 SP1
Pre-installed Software: WinCC Advanced RT V13 (2048 PT) with Logging and Recipes
Licensing: Includes WinCC RT Advanced V14 license package
Connectivity: 2x 10/100/1000 Mbps Ethernet, 4x USB 2.0, 1x RS232 (COM1)
Video Output: 1x DVI-I graphics connection
Power Supply: 24 V DC industrial input
Mounting: Designed for standard DIN rail mounting

Applications

Machine-level HMI and visualization
Data logging and acquisition gateways
Small-scale SCADA control nodes
Process control and monitoring in manufacturing
Embedded control systems requiring a Windows environment

Technical Specifications

Specification	Value
Brand	Siemens
Product Series	SIMATIC IPC277D
Model Number	6ES7647-8AG70-3HA1
Product Type	Nanobox PC
Processor	Intel Atom E660
Processor Speed	1.3 GHz
Memory (RAM)	2 GB
Storage	8 GB SIMATIC PC CompactFlash
Operating System	Windows Embedded Standard 7 SP1
Pre-installed Software	WinCC Advanced RT V13 2048 PT (incl. Logging and Recipes); WinCC RT Adv. V14 License Package
Ethernet Ports	2x 10/100/1000 Mbps RJ45
USB Ports	4x USB V2.0 (High Current)
Serial Port	1x RS232 (COM1)
Graphics Port	1x DVI-I
Expansion Slot	1x CompactFlash Slot
Power Supply	24 V DC
Mounting	Standard Mounting Rail (DIN Rail)
Product Lifecycle Status	Phase-Out
Shipping Weight	2.45 kg
Package Dimensions (Calculated)	22.0 x 10.0 x 18.0 cm
Country of Origin (Estimate)	Germany
Commodity Code	85371091
ECCN	5A992

Installation Guidelines

CRITICAL WARNING: Disconnect all power sources and follow site-specific Lockout/Tagout (LOTO) procedures before installation or maintenance. Failure to de-energize the system can result in electric shock, equipment damage, or serious injury.

1 Securely mount the Nanobox PC onto a standard 35mm DIN rail inside a suitable enclosure, ensuring adequate ventilation and clearance around the unit.
2 Connect a stable, correctly rated 24 V DC industrial power supply to the designated power input terminals. Ensure correct polarity.
3 Connect network cables to the RJ45 Ethernet ports for plant or enterprise network communication.
4 Connect peripherals such as a monitor via the DVI-I port, and keyboard, mouse, or other devices to the USB 2.0 ports as required.
5 Connect any required serial devices to the RS232 COM port.
6 After all connections are verified, re-apply power to the control panel and boot the IPC to begin configuration.

FAQ

What processor is used in this SIMATIC IPC?

This unit is equipped with an Intel Atom E660 processor, which operates at a clock speed of 1.3 GHz.

What software and licenses are included with the 6ES7647-8AG70-3HA1?

It comes pre-installed with Windows Embedded Standard 7 SP1, WinCC Advanced RT V13 (2048 PowerTags), and includes a license package for WinCC RT Advanced V14.

What are the primary communication interfaces on this Nanobox PC?

The device features two 10/100/1000 Mbps Ethernet ports, four high-current USB 2.0 ports, and one RS232 serial port for comprehensive connectivity.

What is the required input voltage for this industrial PC?

The Siemens IPC277D requires a standard 24 V DC industrial power supply for operation.

Is this a current-generation product from Siemens?

No, this specific model is designated as being in the 'Phase-Out' stage of its product lifecycle, meaning it is being discontinued but may still be available for a limited time.
