Description

The 6SE7013-0EP50-Z is a Compact Plus converter from the SIMOVERT MASTERDRIVES series, engineered by Siemens for high-precision motion control applications. This power module is designed for 3-phase operation with an input voltage range of 380–480V AC and provides a power output of 1.1 kW with a nominal current of 3A. Its compact form factor makes it an ideal choice for space-constrained industrial control cabinets. While this unit is currently classified as Obsolete, it remains a standard solution for maintaining legacy production lines that rely on the robust, vector-controlled performance of the Masterdrives family.

Features

• Motion Control Capability: Designed for precise motor management in complex industrial automation.
• Compact Design: The "Compact Plus" form factor saves significant space in electrical enclosures.
• Wide Voltage Compatibility: Operates seamlessly on standard 3-phase industrial power (380–480V).
• Reliable Power Handling: Rated for 1.1 kW at 3A, providing stable performance for small to medium-duty motors.

Technical Specifications

Installation Guidelines

• Mounting: Ensure the converter is mounted vertically on a heat-conductive surface to facilitate passive and active cooling.
• Electrical Safety: Always verify that the line supply voltage matches the rating (380-480V) before energizing to prevent internal power stage damage.
• Thermal Management: Given its compact design, maintain the specified clearance above and below the unit to prevent thermal overload during continuous operation.
• Documentation: Refer to the included CD for specific parameterization, as the "Z" suffix often denotes customer-specific configurations that may deviate from standard units.
• Maintenance: Since this unit is obsolete, ensure that all connections are periodically checked for tightness to avoid resistance-induced heat buildup at terminal blocks.
