Mitsubishi Electric FX3UC-32MT-LT-2 FX3UC Programmable Controller

Остался только 10 товар(ы) на складе

Производитель: Mitsubishi Electric
Номер продукта: FX3UC-32MT-LT-2
Страна происхождения:Соединённые Штаты
Тип продукта: Programmable Logic Controllers
Оплата: Т/Т, Western Union
Вес: 250г
Порт отгрузки: Сямынь
Гарантия: 12 месяцев

Mitsubishi Electric FX3UC-32MT-LT-2 FX3UC Programmable Controller

Description

Engineered for high-density control cabinet environments, the FX3UC-32MT-LT-2 is a compact, high-performance programmable logic controller (PLC) main unit from the Mitsubishi Electric FX3UC series. This controller integrates 32 built-in I/O points, consisting of 16 DC inputs and 16 transistor sink outputs, making it highly suitable for high-speed switching and precise machine control. A key feature of this model is its integrated CC-Link/LT master interface, which enables direct connection to decentralized sensor and actuator networks without the need for additional communication modules. Its slim, connector-type design significantly reduces installation space while maintaining the advanced processing speeds and instruction sets of the FX3 family.

Features

Ultra-compact form factor designed to minimize control panel footprint.
Integrated CC-Link/LT master function for simplified, cost-effective field network deployment.
High-speed program execution and advanced instruction processing capabilities.
32 integrated I/O points (16 inputs and 16 transistor sink outputs) utilizing space-saving ribbon connectors.
Expandable architecture compatible with FX-series extension blocks and special function modules.

Applications

Material handling and automated conveyor systems.
Packaging, labeling, and wrapping machinery.
Decentralized machine-level control networks.
Automated assembly lines and pick-and-place systems.

Technical Specifications

Manufacturer	Mitsubishi Electric
Part Number / Model	FX3UC-32MT-LT-2
Series	FX3UC
Product Type	Programmable Controller (Main Unit)
Total Integrated I/O	32 points
Input Points	16 points (DC inputs)
Output Points	16 points (Transistor sink outputs)
Built-in Network Interface	CC-Link/LT Master
Operating Ambient Temperature	0 to 55 degC (32 to 131 degF)
Storage Ambient Temperature	-25 to 75 degC (-13 to 167 degF)
Operating Ambient Humidity	5 to 95% RH (non-condensing)
Shock Resistance	147 m/s² acceleration, 11ms action time, 3 times by half-sine pulse in X, Y, and Z directions
Noise Resistance	1,000 Vp-p noise voltage, 1 us noise width, 1 ns rise time, 30 to 100 Hz period (via noise simulator)
Grounding	Class D grounding (grounding resistance of 100 ohms or less)
Working Atmosphere	Free from corrosive/flammable gases and excessive conductive dust
Working Altitude	Less than 2000 meters
Weight	Approx. 0.25 kg

Installation Guidelines

Mounting: Install the unit on a standard 35mm DIN rail within an enclosed, dust-free control cabinet.
Grounding: Ensure Class D grounding is established with a dedicated grounding wire. Grounding resistance must be 100 ohms or less.
Wiring: Use appropriate connector cables for the high-density I/O terminals to prevent loose connections and signal interference.
Ventilation: Maintain adequate clearance above and below the unit to ensure natural convection cooling and prevent thermal buildup.

Key Features:

#Mitsubishi Electric FX3UC #Programmable Logic Controllers

What is the main advantage of the FX3UC-32MT-LT-2 controller?

The FX3UC-32MT-LT-2 features an ultra-compact design with a built-in CC-Link/LT master interface, allowing direct connection to decentralized I/O networks without requiring an external master module.

What type of outputs does this PLC use?

This unit is equipped with 16 transistor sink outputs, which are ideal for high-speed switching applications.

What are the grounding requirements for the FX3UC-32MT-LT-2?

It requires Class D grounding with a grounding resistance of 100 ohms or less to ensure stable operation and noise immunity.

What is the operating temperature range for this programmable controller?

The operating ambient temperature range is 0 to 55 degC (32 to 131 degF).
