ABB 07 DI 92 GJR5 2524 00 R0101 Digital input module

Only 6 item(s) left in stock

Manufacturer: ABB
Product No.: 07DI92 GJR5252400R0101
Country of origin:เยอรมนี
Product Type: Digital input module
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 450g
Dimensions: 120 mm W x 140 mm H x 85 mm D
Shipping port: Xiamen
Warranty: 12 months

Description

The ABB 07 DI 92 GJR5 2524 00 R0101, also recognized under the engineering database entry 07DI92 GJR5252400R0101, is a high-density decentralized digital input module designed for the Advant Controller 31 (AC31) core automation platform. Functioning as a remote bus node on the standardized CS31 system bus, this module facilitates localized binary telemetry collation from fields straight to the central processing architecture. This unit incorporates 32 digital input channels configured for 24 V DC monitoring loops. To maximize signal reliability against electromagnetic disruptions and ground tracing errors, the device relies on comprehensive galvanic optocoupler isolation between the binary sensor interface and the internal data backbone. Utilizing an EIA RS-485 link interface, it delivers stable state mapping, transient suppression, and high continuous uptime across chemical, manufacturing, and distribution installations.

Features

Integrates 32 binary inputs rated at a nominal processing voltage threshold of 24 V DC.
Establishes secure multi-drop remote network routing using the verified EIA RS-485 CS31 system bus protocol.
Maintains safe electrical boundaries via internal optocoupler assemblies isolating processing CMOS lines from field-side transients.
Provides comprehensive diagnostics using a front-panel LED matrix dedicated to individual channel values and bus line tracking statuses.
Suppresses erratic mechanical contact bounce and line interference through internal hardware input delay filter configurations.
Simplifies configuration via a manual binary DIL switch array accessible beneath a lateral sliding protective door interface.

Applications

Distributed multi-point limit switch monitoring and digital telemetry aggregation within Advant Controller 31 automation networks.
High-density sensor signal marshaling inside centralized low-voltage switchgear enclosures and remote control desks.
Continuous packaging lines and material handling infrastructure demanding decentralized input mapping with minimal latency.
Remote auxiliary contact tracking for circuit breakers, isolation valves, and emergency shutdown safety interlocks.

Ordering Information

Model	Order Number
07 DI 92 (07DI92) Digital Input Module	GJR5 2524 00 R0101 (GJR5252400R0101)

Technical Specifications

Parameter Category	Technical Specifications
Manufacturer	ABB
Model Designation	07 DI 92 / 07DI92
Order Number	GJR5 2524 00 R0101 / GJR5252400R0101
Product Function	Digital Input Module
System Compatibility	Advant Controller 31 (AC31 / 90 Series)
Network Connection Type	CS31 System Bus (EIA RS-485 Standard)
Total Input Channels	32 Channels
Nominal Supply Voltage	24 V DC
Operational Temperature Envelope	0 to 55 Celsius
Storage Temperature Bound	-25 to 75 Celsius
Galvanic Isolation	Integrated via optocouplers between data backbone and binary process line
Local Status Monitoring	Direct LED panel array mapping channel values and communications diagnostics
Mechanical Dimensions	120 mm Width x 140 mm Height x 85 mm Depth
Net Module Weight	450 g
Country of Origin	Germany
Shipping Weight (Calculated)	0.55 kg
Package Dimensions (Calculated)	135 mm x 155 mm x 100 mm

Installation Guidelines

CRITICAL WARNING: COMPLETE SYSTEM POWER DE-ENERGIZATION REQUIRED

Isolate and lock out all 24 V DC instrumentation loops, auxiliary power supplies, and field signal power links before starting any module configuration, wire termination, or block changeout procedures. Operating or connecting data line plugs during live electrical status can initiate field line transients, generate false PLC execution faults, and cause severe, unrecoverable damage to localized internal CMOS processing chips.

Hook the upper attachment flange of the module over the top edge of a thoroughly grounded standard 35 mm top-hat DIN rail section, applying stable down-and-back physical force until the integrated structural spring clip seats firmly. Alternatively, use four M4 screws to fasten the rear housing plate flat onto a rigid layout subpanel.

Retract the transparent protective dust plate cover located on the right vertical surface of the housing structure. Configure the physical binary switches to match the desired CS31 bus remote station destination index value before initializing loop power configurations.

Lead the discrete multi-point 24 V DC field wires to the respective terminal pin configurations. Use high-integrity copper conductors, utilizing a maximum core sizing profile of 2.5 mm2 for power distribution runs and 1.5 mm2 for individual input processing lines.

Terminate the incoming and outgoing RS-485 serial fieldbus wires of the CS31 framework. Connect the structural cable foil shield material securely to a common earthing bar directly at the control cabinet layout threshold to ensure thorough electromagnetic shielding compliance.

Product Image	Model Number / Title	Condition	Availability	Action
	ABB 07 DO 90-S GJR5 2508 00 R202 AC31-S Safety Binary Output Module	Original New	In Stock	View Details

Key Features:

#Advant Controller 31 #Digital Input Module

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Are the 32 discrete digital inputs on this module electrically isolated from one another?

No, the 32 input channels utilize a shared reference potential internally. However, high-voltage galvanic isolation via integrated optocouplers is maintained between the combined field input channel block and the underlying internal CS31 system bus network components.

How is the target field network address set on this digital input block?

The unique network address is assigned manually via a dedicated binary DIL switch block found behind the slide-open clear protective plastic shield on the right flank of the unit. This step must be performed prior to system startup.

What is the primary function of the integrated hardware filter circuit on the inputs?

The module utilizes an internal hardware signal delay function on its inputs. This delays incoming data to suppress transient induction noise and eliminate mechanical sensor contact bounce before passing the logical state to the master processor.

Is an online application logic download necessary when completing a hot swap or cold module replacement?

No, because the module does not contain independent user application programs or custom project parameter files. When changing a device out, ensure the manual binary DIL address toggles match the replaced device exactly before reconnecting power.
