ABB 3BHE023784R2630 PP D113 B01-26-111000 AC 800PEC Control Processor Module

Description

The 3BHE023784R2630 PP D113 B01-26-111000 is a high-performance control processor module belonging to the ABB AC 800PEC power electronics control system family. This module is designed to provide high-speed processing, robust communication capability, and precise regulation for demanding industrial power electronics applications, such as large-scale drive systems and synchronous excitation equipment.

Integrating versatile interface sub-modules, the system supports dedicated communication protocols including CEX2-Bus RS422 and Anybus/Modbus RTU networks. This ensures reliable real-time data exchange, system expansion connectivity, and deterministic control in multi-layered industrial networks. It is widely deployed within specialized power electronics environments, including the UNITROL 6000 X-power Static Excitation Systems.

Features

• High-speed industrial control processor unit embedded within the AC 800PEC platform.
• Integrated CEX2-Bus RS422 expansion interface via slot ANYIO-1 (U4).
• Flexible Anybus/Modbus RTU communication interface capability via slot ANYIO-2 (U5).
• Modular design featuring multiple factory-configured extension slots (UF D128 modules).
• Ruggedized hardware profile suitable for heavy-duty static excitation and power conversion systems.

Applications

• ABB UNITROL 6000 X-power: Main control loop processing in high-power static excitation systems.
• Power Electronics Control: High-speed regulation loops for massive industrial drives and converters.
• Industrial Synchronous Machines: Automation and electrical excitation management in power generation environments.

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Module Mounting: Secure the controller vertically in the designated cabinet chassis slot using the built-in guide rails and structural mounting screws to withstand ambient operational vibration.
• Cooling and Ventilation: Maintain free space around the unit matching standard enclosure layouts for AC 800PEC setups. Ensure unobstructed vertical airflow path to avoid regional heat concentration.
• Shielding and Grounding: Ensure the chassis frame is bonded to the main functional earth bar via low-impedance connections. Use shielded, twisted-pair cabling for all high-speed RS422 CEX2-Bus and Modbus RTU links to minimize electromagnetic interference (EMI).
• Interface Protection: Keep unused extension slots (U10 to U12) covered with blanking plates to shield internal circuitry from dust, metal particles, and accidental contact.
