Lenze EVS9331-ES 9300-Series Servo Drive

Description

Engineered for high-performance motion control, the EVS9331-ES serves as a robust servo drive within the legacy Lenze 9300-Series portfolio. This industrial servo inverter provides precise speed, torque, and position control for demanding automation applications. Operating with a rated power output of 55.0 kW, the unit is housed in an IP20-rated enclosure designed for control cabinet installation. It supports integration with various fieldbus systems and feedback sensors to maintain dynamic system performance in heavy-duty machinery.

Features

• High-performance vector control and servo functionality.
• Rated power output of 55.0 kW for heavy-duty industrial applications.
• IP20 protection class designed for clean, dry control cabinet environments.
• Modular expansion options for communication and feedback interfaces.
• Comprehensive diagnostic and status monitoring capabilities.

Applications

• Packaging machinery and systems.
• Material handling and conveyor systems.
• Printing and paper processing lines.
• Textile manufacturing machinery.

Technical Specifications

Installation Guidelines

• Mounting: Install vertically inside an IP20-compliant control cabinet to ensure optimal heat dissipation.
• Clearance: Maintain adequate clearance at the top and bottom of the unit to allow unrestricted cooling airflow.
• Grounding: Establish a low-impedance PE connection to the mounting plate to minimize electromagnetic interference (EMI).
• Shielding: Use shielded motor cables and control lines, ensuring the shields are grounded at both ends.
