NB5Q-TW00B | Omron | Programmable Terminal NB Series

The NB5Q-TW00B is a versatile Programmable Terminal (PT) from Omron’s NB series, featuring a compact 5.6-inch TFT LCD display designed for industrial human-machine interface (HMI) applications. This terminal provides a high-quality visualization platform with 65,536 colors and a resolution of 320 × 234 pixels. The unit is equipped with a highly durable resistive-type touch panel, rated for a minimum of 1,000,000 operations, ensuring reliable performance in continuous control environments. With its small physical footprint and user-friendly interface, it is an ideal solution for monitoring and controlling compact machine automation systems.

Features

• 5.6-inch TFT LCD display with vibrant color depth (65,536 colors)
• Resistive touch panel for reliable operator interaction
• High press endurance: min. 1,000,000 cycles
• Compact dimensions (4.6 cm x 18.4 cm x 14.2 cm)
• Lightweight design (approx. 0.620 kg)
• Designed for standard industrial HMI/PT integration

Applications

• Small-scale machine control and monitoring
• Industrial automation operator panels
• HVAC and building automation user interfaces
• Packaging and material handling equipment HMI

Technical Specifications

Installation Guidelines

• Mounting: Ensure the terminal is installed in a panel cutout that provides adequate support and access. Refer to the official installation manual for specific cutout dimensions to ensure an IP-rated seal.
• Environmental Considerations: Install the terminal in a location free from direct sunlight, excessive vibration, and extreme moisture to protect the TFT display and touch surface.
• Wiring: Use appropriate communication cables to connect the PT to your PLC system. Ensure that grounding is properly established to prevent signal noise or static-related performance issues.
• Cleaning: Clean the resistive touch panel surface with a soft, dry cloth. Avoid using organic solvents or abrasive cleaners that could damage the screen overlay.
