Schneider Electric ATS48D32Y Altistart 48 Soft Starter

Description

The ATS48D32Y is an Altistart 48 soft starter designed for the controlled starting and stopping of three-phase asynchronous motors. This unit is rated for a nominal current of 27 A and supports a wide supply voltage range from 208 V to 690 V. With a power handling capacity ranging from 5.5 kW to 22 kW, the ATS48D32Y provides a robust solution for reducing mechanical stress and current surges during motor acceleration in diverse industrial applications.

Features

• Motor Control: Smooth starting and stopping of asynchronous motors to reduce mechanical shock.
• Supply Voltage: Wide operating range of 208 V to 690 V.
• Current Rating: 27 A nominal.
• Power Range: Supports motor power from 5.5 kW up to 22 kW depending on voltage configuration.
• Series: Altistart 48.

Technical Specifications

Installation Guidelines

• Mounting: Ensure the soft starter is installed vertically on a level surface to facilitate optimal heat dissipation.
• Ventilation: Maintain adequate clearance around the unit as specified in the technical manual to prevent thermal overload.
• Wiring: Connect the power supply to the input terminals and the motor to the output terminals, ensuring all connections are tightened to the specified torque.
• Grounding: Always connect the protective earth (PE) terminal to a secure system ground.
• Configuration: Verify that the supply voltage matches the settings configured in the starter control parameters before commissioning.
