Schneider Electric TSXPSY1610MC Modicon Premium Power Supply Module

Description

The Schneider Electric TSXPSY1610MC is a power supply module engineered for the Modicon Premium automation platform. This module provides a 24 V DC output with a maximum current capacity of 1500 mA, ensuring stable power delivery for PLC components and associated I/O modules. Featuring an IP20 ingress protection rating, it is designed for integration into electrical control cabinets where it serves as a reliable power source for critical industrial control architectures.

Features

• 24 V DC output voltage
• 1500 mA maximum current capacity
• Form factor optimized for Modicon Premium rack systems
• IP20 ingress protection rating
• Engineered for reliable power distribution in industrial automation

Applications

• Modicon Premium PLC power management
• Industrial control panel power distribution
• Automation system infrastructure support
• Maintenance and replacement for legacy control systems

Technical Specifications

Installation Guidelines

• Rack Mounting: Slide the module into the dedicated power supply slot on the Modicon Premium rack and ensure the latch is fully secured.
• Wiring: Connect the DC output terminals to the rack power bus, ensuring proper polarity to prevent damage to the PLC components.
• Grounding: Verify that the rack assembly is securely connected to a common protective earth bus to maintain electrical safety.
• Verification: Use the integrated diagnostic features to verify output voltage stability before connecting load modules.
• Environment: Install within an appropriate control enclosure to protect the IP20-rated electronics from conductive dust, moisture, and corrosive atmospheres.
