Schneider TeSys GV2-L08 Magnetic Circuit Breaker

Description

The GV2-L08 is a TeSys GV2L magnetic circuit breaker designed for the protection of electrical circuits and motor applications. This unit features a rated operational current of 4 A and utilizes secure screw terminal connectors for reliable field wiring. As a magnetic-only protection device, the GV2-L08 provides rapid response to short-circuit faults, ensuring the safety and integrity of connected electrical components within industrial and commercial distribution systems.

Features

• Magnetic-only trip protection
• Rated current: 4 A
• Secure screw terminal connections
• Compact design for DIN rail mounting
• Robust protection against short-circuit events

Applications

• Motor control centers
• Industrial electrical distribution
• Automation cabinet protection
• Branch circuit management

Technical Specifications

Installation Guidelines

• Mounting: Snap the circuit breaker onto a standard 35 mm DIN rail or mount directly to a backplane using screws. Ensure vertical alignment for optimal performance.
• Wiring: Use appropriately rated copper conductors. Insert wires into the screw terminals and tighten to the specified torque settings to ensure low-resistance contacts.
• Safety: Disconnect power before installation or maintenance. Verify that the breaker rating matches the protection requirements of the connected load.
• Environment: Install in a clean, dry enclosure to prevent the accumulation of conductive dust or moisture, which could affect breaker operation.
