Delta Electronics VFD13AMH43ANSAA MH300 Series Variable Frequency Drive

Stokta sadece 10 adet kaldı

Üretici: Delta Electronics
Ürün No.: VFD13AMH43ANSAA
Menşei ülke:Amerika Birleşik Devletleri
Ürün Türü: Variable Frequency Drives
Ödeme: T/T, Western Union
Ağırlık: 4000g
Gönderim limanı: Xiamen
Garanti: 12 ay

Description

Engineered for precise speed and torque control of three-phase AC induction and synchronous motors, the Delta Electronics VFD13AMH43ANSAA is a high-performance variable frequency drive belonging to the MH300 Series. Designed to handle both heavy-duty and normal-duty operating profiles, this compact frequency converter offers dynamic motor regulation with flexible carrier frequency adjustments. It operates directly from a 380V to 480V AC grid, providing robust electrical safety and reliable operation across diverse industrial automation architectures.

The unit features a fanless, natural cooling design which eliminates a common mechanical point of failure, making it highly suitable for environments where fan maintenance is restricted. With integrated support for multiple motor control modes and safe torque off functionality, this drive ensures seamless integration into modern factory control networks and machinery setups.

Features

Dual-rating capabilities optimizing performance for heavy-duty (HD) and normal-duty (ND) industrial machinery applications.
Natural cooling design utilizing a high-efficiency heatsink configuration to eliminate mechanical fan maintenance requirements.
Wide input voltage tolerance of -15% to +10% to ensure operational stability during grid fluctuations.
Adjustable carrier frequency ranging from 2 kHz to 15 kHz to manage acoustic motor noise and thermal constraints.
IP20-rated protective housing suitable for panel mounting within clean, dry industrial enclosures.

Applications

Machine tool spindles and metalworking systems.
Textile machinery and high-speed spinning frames.
Woodworking cutting and routing equipment.
Packaging, labeling, and processing conveyors.
Centrifugal fans, pumps, and localized ventilation installations.

Technical Specifications

Manufacturer	Delta Electronics
Model / Part Number	VFD13AMH43ANSAA
Series	MH300 Series
Frame Size	D
Nominal Input Voltage	3-phase AC 380V to 480V (-15% to +10%)
Operating Voltage Range	323 to 528 Vac
Input Frequency Range	47 to 63 Hz
Applicable Motor Output (Heavy Duty)	5.5 kW (7.5 HP)
Rated Output Capacity (Heavy Duty)	9.9 kVA
Rated Output Current (Heavy Duty)	13.0 A
Rated Input Current (Heavy Duty)	14.3 A
Applicable Motor Output (Normal Duty)	7.5 kW (10 HP)
Rated Output Capacity (Normal Duty)	11.1 kVA
Rated Output Current (Normal Duty)	14.5 A
Rated Input Current (Normal Duty)	16.0 A
Carrier Frequency	2 to 15 kHz (Factory setting: 4 kHz)
Cooling Method	Natural cooling
Ingress Protection Rating	IP20
Shipping Weight	4.0 kg

Installation Guidelines

Mount the unit vertically on a flat, non-flammable surface inside a control cabinet to allow proper vertical convective airflow.
Ensure clearance zones around the heatsink conform to OEM technical standards for natural cooling dissipation.
Ground the drive using a low-impedance connection directly to the main system ground terminal.
Utilize shielded motor cables and route control wiring separately from power and motor lines to minimize electromagnetic interference.

Key Features:

#Delta MH300 Series #Variable Frequency Drives

What is the power rating of the Delta VFD13AMH43ANSAA?

The drive features a dual rating system. For heavy-duty operation, it supports an applicable motor output of 5.5 kW (7.5 HP) with a rated output current of 13.0 A. For normal-duty operation, it supports up to 7.5 kW with a rated output current of 14.5 A.

What cooling method does the VFD13AMH43ANSAA use?

This drive relies entirely on natural cooling (heatsink dissipation) and does not contain integrated cooling fans, making it ideal for quiet environments and reducing mechanical wear.

What are the input voltage tolerances for this variable speed drive?

The drive has a nominal input voltage of 3-phase AC 380V to 480V (with a tolerance of -15% to +10%), resulting in an acceptable operational voltage window of 323 to 528 Vac.

Does the VFD13AMH43ANSAA include an internal EMC filter?

No, the 'N' in the part number indicates that the built-in EMC filter is not included in this configuration. An external filter can be installed if EMC compliance is required.

What is the IP rating of this unit?

This variable frequency drive has an IP20 ingress protection rating, which requires installation inside a suitable, clean, and dust-free control cabinet.
