Delta VFD17AMH43ANSAA Variable Speed AC Motor Drives MH Series

Only 10 item(s) left in stock

Manufacturer: Delta Electronics
Product No.: VFD17AMH43ANSAA
Country of origin:Hoa Kỳ
Product Type: Variable Speed AC Motor Drives
Payment: T/T, Western Union
Weight: 4000g
Shipping port: Xiamen
Warranty: 12 months

Xem toàn bộ chi tiết

Description

The Delta VFD17AMH43ANSAA is a high-performance frequency converter variable speed AC motor drive from the MH Series, engineered for versatile industrial motor control. This AC drive supports both heavy-duty and normal-duty applications, with an applicable motor output of 7.5kW (10HP). It operates on a 3-phase 380V to 480V input, providing robust speed regulation for machinery requiring high torque or efficient energy management. With a rated output current of 17.5 A in heavy-duty mode and 19.8 A in normal-duty mode, this unit is designed to integrate seamlessly into diverse industrial automation systems.

Features

Dual-Mode Operation: Flexibility to switch between Heavy Duty and Normal Duty operating profiles depending on application severity.
Wide Operating Input Range: Accepts mainline inputs across a broad voltage tolerance spanning 323 to 528 Vac.
Variable Carrier Frequency: Adjustable PWM modulation between 2 to 15 kHz with an optimized factory default setting of 4 kHz.
Compact Frame D Layout: Standardized mechanical enclosure envelope for streamlined spatial planning inside electric panels.
IP20 Ingress Rating: Standard finger-safe protection suitable for centralized industrial control cabinet housing.
EMC Compliance: Full infrastructure provisions for optional electromagnetic compatibility filter attachments.

Applications

Industrial processing fans and automated fluid pump flow control networks.
Heavy material handling conveyor systems and dynamic logistics sorting grids.
Precision packaging machinery and high-speed vertical scaling apparatus.
Textile manufacturing equipment, weaving looms, and specialized tension unwinders.
Machine tool spindle drives demanding synchronous speed stabilization and high initial start torque.

Technical Specifications

Feature Category	Technical Specification Detail
General Data	Manufacturer: Delta Products Model Number: VFD17AMH43ANSAA Series Designation: MH Series Product Type: Variable Speed AC Motor Drive
Power Output	Applicable Motor Output: 7.5 kW (10 HP) Heavy Duty Rated Current: 17.5 A Normal Duty Rated Current: 19.8 A
Electrical Input	Rated Input Voltage: 3-phase 380V to 480V, 50/60 Hz Operating Voltage Range: 323 to 528 Vac Frequency Tolerance: 47 to 63 Hz
Enclosure & Mechanical	Ingress Protection: IP20 Chassis Frame size: Frame D Architecture Cooling Method: Natural cooling convection
Logistics	Shipping Weight: 4 kg Country of Origin: Taiwan / China

Installation Guidelines

Engineering Category	Detailed Mechanical & Electrical Requirements
Mounting & Positioning	Install the AC drive strictly in a vertical orientation inside a dust-free control cabinet. Ensure the mounting plane is flat and rigid to shield the electronics from mechanical vibrations and sudden physical shock waves.
Thermal Clearance	Because this unit utilizes natural cooling convection, maintain an open, unobstructed safety clearance perimeter around the chassis. Allow sufficient airflow so that internal cabinet temperatures remain well below environmental thresholds.
Power Wiring Sizing	Dimension all electrical input mains and output motor cables based on load configurations. Ensure copper wire cross-sections comply with continuous input ratings (Heavy Duty: 19.3 A / Normal Duty: 21.8 A) and local NEC electrical code mandates.
Grounding & Noise Safety	Establish a direct, low-impedance ground circuit connection between the drive chassis terminal and the main power panel PE ground bus. Correct bonding is essential to suppress electromagnetic noise and eliminate leakage hazards.
Environmental Factors	Do not install the electronics assembly in processing areas exposed to high concentrations of conductive carbon dust, fine moisture aerosols, or aggressive chemical compounds that trigger circuit trace failures.

Key Features:

#Delta MH Series #Variable Speed AC Motor Drives

What is the motor output capacity of the VFD17AMH43ANSAA?

This drive supports a motor output of 7.5 kW (10 HP).

Does the VFD17AMH43ANSAA support both heavy and normal duty?

Yes, it provides performance specifications for both heavy-duty (17.5 A output) and normal-duty (19.8 A output) operation.

What is the IP rating for this drive?

This model has an Ingress Protection rating of IP20.

What is the operating voltage range for this drive?

The operating voltage range is 323 to 528 Vac.
