Mitsubishi Electric HF-SP152B HF-SP Servo Motor

Description

Engineered for high-performance motion control, the Mitsubishi Electric HF-SP152B is a medium-inertia AC servo motor designed to deliver precise positioning and reliable speed regulation within industrial automation systems. Operating on a 200V AC power supply, this 1.5 kW motor is equipped with an integrated electromagnetic holding brake, making it highly suited for vertical axis applications or systems requiring a secure mechanical hold during power-off states. The robust design ensures stable load matching and excellent dynamic response under varying industrial loads.

Features

• Medium-inertia design optimizes load-to-motor inertia matching for stable operation.
• Integrated electromagnetic holding brake prevents axis slippage during power loss or system shutdown.
• High-resolution encoder compatibility ensures precise closed-loop feedback and positioning accuracy.
• IP67 environmental protection rating (excluding the shaft-through portion) provides high resistance to dust and moisture.
• Optimized thermal dissipation design supports continuous duty cycles in demanding environments.

Applications

• Vertical axis control (Z-axis) in CNC machining centers and gantry systems.
• Material handling systems, automated conveyors, and transfer lines.
• Packaging, labeling, and wrapping machinery requiring synchronized motion.
• Textile machinery and printing presses.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting: Ensure the motor is securely bolted to a rigid, vibration-free mounting surface. Align the shaft precisely with the load coupling to prevent premature bearing wear.
• Grounding: Connect the motor's protective earth terminal directly to the system ground to minimize electromagnetic interference (EMI).
• Cable Routing: Keep power and encoder cables separated by a minimum distance to prevent signal noise. Use shielded cables for all encoder connections.
• Thermal Management: Maintain adequate clearance around the motor frame to allow natural convection cooling. Do not exceed the maximum ambient operating temperature of 40 degC.

Compliance and Certifications

• CE Mark
• UL Listed
• cUL Certified
