Siemens 6ES7313-6CG04-0AB0 | SIMATIC S7-300 | CPU 313C-2 DP Kompakt-CPU

Description

The 6ES7313-6CG04-0AB0 is a SIMATIC S7-300 CPU 313C-2 DP, a compact CPU module designed for scalable automation solutions. It features integrated MPI and PROFIBUS DP interfaces, making it highly effective for distributed control architectures. This module includes 16 digital inputs and 16 digital outputs, complemented by 3 high-speed counters capable of processing frequencies up to 30 kHz. With a 128 KB work memory and an integrated 24 V DC power supply, the 6ES7313-6CG04-0AB0 provides efficient processing for demanding production environments. A Micro Memory Card (MMC) is required for operation, and the unit utilizes a 40-pole front connector for streamlined field wiring. This model supports firmware versions V3.3.7 and V3.3.11.

Features

• Integrated Interfaces: Built-in MPI and PROFIBUS DP interface for flexible communication.
• Compact I/O: Includes 16 digital inputs and 16 digital outputs.
• High-Speed Processing: Equipped with 3 high-speed counters (up to 30 kHz).
• Memory: 128 KB work memory for automation program storage.
• Firmware: Supports firmware versions V3.3.7 and V3.3.11.
• System Integration: Requires a 40-pole front connector and Micro Memory Card.

Applications

• Distributed automation solutions via PROFIBUS DP
• High-speed pulse processing and position monitoring
• Industrial production line control
• Retrofitting and upgrading existing S7-300 control systems
• Process control requiring precise digital I/O management

Technical Specifications

Installation Guidelines

• Mounting: Install on a standard 35mm DIN rail. Ensure proper clearance for ventilation to maintain optimal operating temperature.
• Power Connection: Connect 24V DC to the integrated power supply terminals. Ensure the voltage remains within the 19.2-28.8V DC range.
• Wiring: Use a 40-pole front connector for I/O wiring. Ensure all cables are properly shielded to mitigate electromagnetic interference.
• Memory Management: A Micro Memory Card must be inserted into the designated slot before the CPU can perform program execution.
• Configuration: Use compatible STEP 7 engineering software to configure the DP interface and assign I/O parameters.
