BECKHOFF EP2817-0008 EtherCAT Box 24-Channel Digital Output Module

Description

High-density control routing in demanding industrial field environments is streamlined using the EP2817-0008 EtherCAT Box. This decentralized digital output module integrates 24 digital channels within a compact, hardened form factor, bypassing the need for protective control cabinets. It interfaces directly with field actuators via a robust 25-pin D-sub connection and utilizes the high-speed EtherCAT protocol for real-time automation architectures.

The module is engineered for maximum operational reliability, featuring individual short-circuit protection across all 24 channels. It is capable of switching various load profiles, including ohmic, inductive, and lamp loads, making it highly adaptable for complex industrial machinery and decentralized I/O structures. Integrated diagnostic features, such as undervoltage detection for control and peripheral voltages, ensure system downtime is minimized through rapid error localization.

Features

• 24 high-density digital outputs housed in an IP67 fieldbus-ready casing.
• Robust 25-pin D-sub connection terminal with UNC4-40 locking threads for secure signal routing.
• Individual short-circuit protection on each digital output channel.
• Compatible with ohmic, inductive, and lamp loads.
• Supports EtherCAT Distributed Clocks for ultra-precise synchronization in time-critical applications.
• Built-in undervoltage detection for auxiliary and power supplies below 18 V DC.
• Environmentally sealed design requiring no protective terminal box.

Applications

• Decentralized robotics and end-of-arm tooling control.
• High-speed packaging and sorting machinery.
• Automotive manufacturing assembly lines and conveyor systems.
• Material handling and warehousing automation.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mount the EtherCAT Box directly to the machine frame or mounting plate using the integrated mounting holes.
• Ensure all unused M8 and D-sub ports are sealed with the appropriate protective caps to maintain the IP65/66/67 rating.
• Route power feed lines using shielded M8 cables to reduce electromagnetic interference in high-noise environments.
• Ensure the system ground is connected securely via the metal screw contacts on the EtherCAT Box.

Compliance and Certifications

• CE
• UL
