سیمنس 6GK5788-1GD00-0AB0 نقطه دسترسی IWLAN SCALANCE W788-1

Description

The 6GK5788-1GD00-0AB0 is a high-performance SCALANCE W788-1 M12 industrial wireless LAN (IWLAN) access point, engineered for reliable data communication in demanding industrial environments. Featuring one radio module and three N-Connect antenna ports, it supports the IEEE 802.11a/b/g/h/n standards across both 2.4 GHz and 5 GHz frequency bands, delivering a gross data rate of up to 450 Mbit/s per radio. The unit is designed for durability with an IP65 degree of protection and operates within an ambient temperature range of -20 degC to +60 degC. Connectivity is managed via a high-speed 1 Gbit/s M12 port and redundant 24 V DC power supply inputs. Advanced security is handled via WPA2/802.11i/e protocols, and it features a plug slot for additional "iFeatures" via a Key Plug.

Features

• Radio Standard: IEEE 802.11a/b/g/h/n (2.4/5 GHz dual-band support).
• Throughput: Gross 450 Mbit/s per radio.
• Connectivity: 1x M12 port (max. 1 Gbit/s) and 3x N-Connect antenna ports.
• Power: Redundant 24 V DC input and Power-over-Ethernet (PoE) support.
• Durability: IP65-rated housing suitable for harsh industrial settings.
• Security: WPA2/802.11i/e support for secure wireless transmission.
• Feature Expansion: Support for iFeatures via optional Key Plug.

Applications

• Industrial automation and mobile robotic systems (AGVs).
• Real-time machine-to-machine (M2M) communication.
• Wireless infrastructure for manufacturing logistics and tracking.
• High-availability industrial control networks.
• Data acquisition in areas difficult to cable.

Technical Specifications

Installation Guidelines

• Mounting: Ensure the device is mounted securely in a location that minimizes obstructions to maintain the wireless signal integrity.
• Antenna Placement: Connect antennas to the three N-Connect ports; ensure correct orientation for the required radio coverage pattern.
• Powering: Utilize redundant 24 V DC power feeds or PoE as required by the installation design; ensure M12 A-coded connectors are properly seated.
• Regional Compliance: Note that this specific model is restricted to operation in the USA; always verify national radio approvals before deployment.
• Configuration: Use the provided software tools via the Ethernet interface to configure security (WPA2) and network parameters.
