واحد مبدل فشرده SIMOVERT MASTERDRIVES زیمنس 6SE7016-1EA30

Description

The 6SE7016-1EA30 is a SIMOVERT MASTERDRIVES compact converter unit engineered for the precise speed and torque control of 3-phase AC motors. As a base drive unit within the Siemens product ecosystem, this device is designed for integration into industrial control panels where reliable power conversion is required for production machinery.

This converter operates on a 3-phase supply voltage ranging from 380 V to 460 V at 50/60 Hz. It provides a nominal power output of 4 kW and supports a rated current of 10.2 A. Featuring an IP20 protection rating, the 6SE7016-1EA30 is suitable for installation in protected environments or cabinets, offering a modular architecture that allows for the expansion of control and communication functionality through additional sub-modules.

Features

• Compact physical design optimized for cabinet mounting
• 3-phase input voltage range: 380-460 V AC
• Nominal power rating: 4 kW
• Rated current output: 10.2 A
• Modular architecture supporting supplementary option cards
• IP20 ingress protection

Applications

• Conveyor systems and material handling
• Pump and fan speed control
• Processing machinery requiring variable frequency control
• General industrial automation drive systems

Technical Specifications

Installation Guidelines

• Mounting: Designed for vertical installation within a ventilated control cabinet to ensure adequate heat dissipation.
• Cooling: Ensure the ventilation path is unobstructed; internal cooling fans must have sufficient clearance from cabinet walls or adjacent components.
• Grounding: A high-integrity protective earth (PE) connection must be established to the drive chassis to ensure electromagnetic compatibility and safety.
• Cable Routing: Separate power supply cabling from sensitive signal and communication wiring to mitigate electromagnetic interference (EMI).
• Environment: Installation location must be free from conductive dust, corrosive gases, and excessive moisture to maintain the IP20 integrity.
