Omron-CS1H-CPU67H

Description

Designed to handle complex, high-speed machine control and extensive data management, the Omron CS1H-CPU67H stands as a high-performance central processing unit within the CS1 series programmable logic controller (PLC) lineup. This processor delivers rapid instruction execution and a high-capacity memory structure, making it highly effective for large-scale manufacturing lines and precise process control systems. By supporting up to seven expansion racks, this controller allows industrial facilities to scale their input/output configurations seamlessly without sacrificing cycle times.

The unit features integrated dual-port communications, enabling simultaneous maintenance programming and human-machine interface (HMI) data transmission. Its advanced architecture handles complex floating-point math and structured programming blocks efficiently, ensuring optimal performance for demanding motion control, material handling, and plant-wide automation tasks.

Features

• Highly rapid processing speed with basic instructions executed in as little as 0.02 microseconds.
• Generous program capacity supporting up to 250K steps to accommodate complex control logic.
• Expansive data memory allocation of 448K words, suitable for intensive data logging and recipe storage.
• Comprehensive system scalability, supporting up to 5,120 local I/O points across 7 expansion racks.
• Dual built-in communication interfaces, featuring a standard RS-232C port and a dedicated peripheral port.
• Robust fault-diagnosis features and background execution capability to minimize system downtime.

Applications

• Automobile assembly and parts manufacturing lines.
• Large-scale water and wastewater treatment systems.
• High-speed packaging, sorting, and distribution systems.
• Chemical processing plants requiring coordinated process loop control.
• Power generation and auxiliary substation automation systems.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mount the CPU unit securely onto the dedicated CS1 backplane inside a protective, dust-free industrial enclosure.
• Always shut off the main system power supply before mounting or removing the CPU module.
• Ensure reliable grounding of the PLC rack to a dedicated ground point of 100 ohms or less.
• Separate all low-voltage communication cables (RS-232C, peripheral) from high-voltage AC power lines to avoid electromagnetic interference.
• Maintain adequate physical clearance above and below the CPU unit to guarantee proper air convection and thermal dissipation.

Compliance and Certifications

• CE Compliant
• UL and cULus Listed
• Lloyd's Register Approved
