Schneider Modicon Quantum 180CPX12000 Module d'alimentation

Il ne reste que 10 article(s) en stock

Fabricant : Schneider Electric
N° de produit : 180CPX12000
Pays d'origine :France
Type de produit : Modules d'alimentation
Paiement : Virement bancaire, Western Union
Poids : 730g
Dimensions : 16.5 x 31.0 x 5.0 cm
Port d'expédition : Xiamen
Garantie : 12 mois

Voir les détails complets

Integrating directly into specialized PC-based control architectures, the Schneider Electric 180CPX12000 serves as a highly reliable Atrium auxiliary power supply module within the Modicon Quantum hardware ecosystem. This module is engineered to provide stable, continuous auxiliary power to co-processor cards, ensuring critical control logic and communication states are preserved even during primary PC chassis power cycles or system reboots.

Key Features

Dedicated auxiliary power delivery designed specifically for the Modicon Quantum Atrium slot-card systems.
Maintains system state and register integrity during host PC power-downs and maintenance cycles.
Compact, robust form factor optimized for standard industrial enclosure mounting and integration.
Fully testable component allowing for straightforward verification of operational integrity during commissioning.

Industrial Applications

PC-based industrial control systems utilizing Atrium co-processors.
Legacy Modicon Quantum control system maintenance and infrastructure support.
Continuous process monitoring systems requiring non-volatile state preservation during host reboots.

Technical Specifications

Parameter	Specification
Manufacturer	Schneider Electric
Model Number	180CPX12000
Product Series	Modicon Quantum / Atrium
Module Type	Auxiliary Power Supply Module
Lifecycle Status	Phase-Out (Legacy Support)
Country of Origin	France
Commodity Code	85389091
Export Control Classification (ECCN)	N
Shipping Weight (Calculated)	0.73 kg
Package Dimensions (Calculated)	16.5 x 31.0 x 5.0 cm

Empirical Engineering Insights

Alternative Models & Compatibility

The 180CPX12000 is specifically tailored for Atrium slot-card architectures. When replacing older revisions of this module, ensure that the auxiliary power cabling harness matches the pin configuration of your existing PC-based backplane interface.

Application Pitfalls & Engineering Notes

In high-vibration environments or inside standard industrial PC chassis, ensure the auxiliary power cable is securely anchored. A momentary loss of auxiliary power during a host PC reboot will trigger a cold-start routine on the Atrium co-processor, clearing un-backfilled registers and interrupting fieldbus communications.

Commissioning & Wiring Tips

Always verify the ground potential between the auxiliary power source and the PC chassis. Ground loops in auxiliary power lines can introduce high-frequency noise into the Atrium backplane bus, leading to intermittent communication dropouts or diagnostic faults.

Installation Guidelines

CRITICAL WARNING

Before installing or removing the auxiliary power supply module, completely de-energize the host PC chassis and all connected field wiring. Failure to isolate the power sources can result in equipment damage, electrical shock, or unexpected control system behavior.

Mount the module securely within the designated slot or panel space, ensuring adequate clearance for thermal dissipation.

Connect the auxiliary power harness to the module, verifying correct polarity and secure terminal seating.

Perform a continuity and ground check before energizing the system to prevent ground loops.

Key Features:

#Modicon Quantum #Power Supply Modules

What is the primary function of the 180CPX12000 module?

The 180CPX12000 is an Atrium auxiliary power supply module designed to provide continuous backup power to co-processor cards in Modicon Quantum PC-based control systems, preventing data loss during host PC power cycles.

Is the 180CPX12000 compatible with standard Modicon Quantum backplanes?

It is specifically designed for the Atrium PC-based control slot-card architecture. Verify your specific backplane and cabling configuration before installation.

What happens if auxiliary power is lost on the 180CPX12000?

A loss of auxiliary power during a host PC reboot will cause the Atrium co-processor to undergo a cold start, which clears un-backfilled registers and interrupts active communication states.
