Siemens 6ES7151-1BA00-0AB0 SIMATIC ET 200S IM 151-1 Standard Interface Module

Il ne reste que 3 article(s) en stock

Fabricant : Siemens
N° de produit : 6ES7151-1BA00-0AB0
Pays d'origine :Allemagne
Type de produit : Interface Module
Code-barres : 8537101190
Paiement : Virement bancaire, Western Union
Poids : 950g
Dimensions : 2.5 cm x 5.1 cm x 83.8 cm
Port d'expédition : Xiamen
Garantie : 12 mois

Voir les détails complets

Description

The Siemens 6ES7151-1BA00-0AB0 is an IM 151-1 Standard Interface Module designed as the head module for the SIMATIC ET 200S distributed I/O system. This module provides a compact and cost-effective solution for integrating the ET 200S station into a PROFIBUS DP network, facilitating seamless communication within larger automation architectures. It is engineered to manage a substantial I/O configuration, supporting the connection of up to 63 electronic or motor starter modules on its backplane bus, allowing for the creation of highly distributed control stations directly on the machine. The 6ES7151-1BA00-0AB0 efficiently handles a maximum address space of 244 bytes for both inputs and outputs, ensuring robust data capacity for a wide array of applications. This Siemens interface module offers a dependable choice for users requiring a reliable PROFIBUS DP connection without the advanced features of a High Feature version.

Features

Head module for Siemens SIMATIC ET 200S distributed I/O systems.
Connects ET 200S stations to a PROFIBUS DP network.
Supports up to 63 electronic or motor starter modules.
Maximum I/O address space of 244 bytes for inputs and outputs.
Designed for standard PROFIBUS DP applications.

Applications

Distributed I/O systems in industrial automation.
Machine-level control systems requiring PROFIBUS DP connectivity.
Integration of remote I/O into larger PLC-based architectures.
Cost-effective expansion of control systems with standard functionality.

Technical Specifications

Attribute	Value
Model Number	6ES7151-1BA00-0AB0
Module Type	Interface Module
Manufacturer	Siemens
Product Range	Siemens SIMATIC ET 200S
System Compatibility	PLC
Condition	Brand New
Product Status	Active
Communication Service	Ethernet router
Network Connectivity	PROFIBUS DP
Max. I/O Modules Supported	63 (electronic or motor starter)
Max. I/O Address Space	244 bytes (inputs and outputs)
Lead Time	In Stock
Minimum Order Quantity (MOQ)	1
Shipping Weight	0.95 kg
Package Dimensions (Calculated)	2.5 cm x 5.1 cm x 83.8 cm
Country of Origin	GERMANY
HS Code	8537101190

Installation Guidelines

De-energize System: Ensure all power to the ET 200S system and associated components is disconnected before installation or removal of the module.
Mounting: Securely mount the 6ES7151-1BA00-0AB0 interface module onto the designated DIN rail within the ET 200S station.
Module Placement: Ensure proper seating of the interface module as the first module in the ET 200S station, connecting it to the backplane bus.
PROFIBUS DP Connection: Connect the PROFIBUS DP cable to the module's designated communication port, ensuring correct polarity and secure termination.
Grounding: Verify proper grounding of the ET 200S station and the PROFIBUS DP shield to minimize electrical interference.
Power-Up: After all connections are verified, re-energize the system and observe module status indicators for correct operation.

Key Features:

#Interface Module #SIMATIC ET 200S

What is the primary function of the Siemens 6ES7151-1BA00-0AB0 module?

It serves as the head module for the SIMATIC ET 200S distributed I/O system, connecting it to a PROFIBUS DP network.

How many I/O modules can the 6ES7151-1BA00-0AB0 support?

It supports the connection of up to 63 electronic or motor starter modules on the backplane bus.

What is the maximum I/O address space handled by this module?

The module efficiently handles a maximum address space of 244 bytes for both inputs and outputs.

Is this module suitable for advanced PROFIBUS DP applications?

This is the 'Standard' version, designed for robust PROFIBUS DP connections for typical applications, not requiring the advanced features of a 'High Feature' version.
