BECKHOFF C6015-0010 Ultra-Compact Industrial PC

Hanya 10 item tersisa di stok

Produsen: BECKHOFF
Nomor Produk: C6015-0010
Negara asal:Jerman
Jenis Produk: Industrial PCs
Pembayaran: T/T, Western Union
Berat: 2000g
Dimensi: 82 x 82 x 40 mm
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

BECKHOFF C6015-0010 Ultra-Compact Industrial PC

Description

Designed for space-constrained control cabinet installations, the BECKHOFF C6015-0010 delivers high-performance processing in an exceptionally small footprint. This ultra-compact industrial PC leverages Intel Atom processors to execute demanding automation, visualization, and communication tasks directly at the machine level. Its robust, fanless design ensures long-term reliability in harsh industrial environments, making it an ideal hardware platform for TwinCAT-based control systems.

Featuring an aluminum zinc die-cast housing, the device is engineered for passive cooling via a single-side cooling plate. With dual on-board Gigabit Ethernet interfaces and versatile USB connectivity, the C6015-0010 integrates seamlessly into modern industrial networks, serving as an efficient edge gateway, controller, or decentralized data acquisition node.

Features

Extremely compact form factor optimized for space-saving control cabinet installation.
Robust aluminum zinc die-cast housing for enhanced mechanical durability.
Passive cooling design utilizing a single-side cooling plate for maintenance-free, fanless operation.
Dual on-board Gigabit Ethernet ports for high-speed network communication and OT/IT integration.
Flexible mounting configurations including rear-wall, side-wall, or DIN rail installation.
Dedicated M.2 SSD slot for reliable, solid-state storage.

Applications

Machine control and decentralized automation systems
Industrial Internet of Things (IIoT) gateways and edge computing
Data acquisition, logging, and protocol conversion
Building automation and infrastructure monitoring systems

Technical Specifications

Manufacturer	BECKHOFF
Part Number/Model	C6015-0010
Device Type	Ultra-compact control cabinet PC
Processor	Intel Atom E3815, 1.46 GHz, 1 core (Option: up to Intel Atom E3845 1.91 GHz, 4 cores)
Motherboard	Compact motherboard for Intel Atom E38xx
Memory	2 GB DDR3L RAM (Option: up to 4 GB DDR3L RAM ex factory)
Graphic Adapter	Integrated in the processor
Storage	40 GB M.2 SSD (Option: up to 160 GB M.2 SSD)
Ethernet Ports	2 x 100/1000BASE-T on-board
Interfaces	1 x USB 3.0, 1 x USB 2.0, 1 x DisplayPort
Power Supply	24 V DC (Option: UPS)
Housing Material	Aluminum zinc die-cast
Protection Rating	IP20
Operating Temperature	0 to 55 degC
Dimensions (W x H x D)	82 x 82 x 40 mm (3.2" x 3.2" x 1.6") without mounting plate
Weight	2.0 kg (Shipping Weight)

Connections and Interfaces

Interface Port	Function / Specification
Ethernet 1 & 2	2 x RJ45 (100/1000BASE-T) for network connection and EtherCAT control
USB 3.0	1 x High-speed USB port for external storage or peripherals
USB 2.0	1 x Standard USB port for input devices or configuration tools
DisplayPort	1 x Digital video output for HMI or external monitors
Power Input	24 V DC terminal connection

Installation Guidelines

Mounting: Secure the device using the standard rear-wall mounting sheet. Ensure the mounting surface is flat and stable. Optional side-wall or DIN rail mounting kits must be used in accordance with Beckhoff specifications.
Cooling & Clearance: To maintain passive thermal dissipation, a minimum free space of 5 cm (2 inches) is strictly required above and below the PC. Do not block the air circulation path around the cooling plate.
Power Connection: Connect to a stabilized 24 V DC power supply. Ensure proper grounding of the housing to prevent electromagnetic interference (EMI) and protect internal components.
Environmental Conditions: Operate only within the specified temperature range of 0 to 55 degC. Avoid installation in environments with high humidity, conductive dust, or corrosive gases.

Key Features:

#Beckhoff C6015 #Industrial PCs

What are the cooling requirements for the BECKHOFF C6015-0010?

The C6015-0010 features passive cooling with a single-side cooling plate. It requires a minimum free space of 5 cm (2 inches) on both the top and bottom of the unit for proper air circulation.

What mounting options are available for this industrial PC?

The unit comes standard with a mounting sheet for rear-wall installation. Optional mounting configurations include side-wall mounting or DIN rail installation.

What operating systems are supported by the C6015-0010?

It supports Windows Embedded Compact 7 (standard), with options for Windows 7, Windows Embedded Standard 7, and Windows 10 IoT Enterprise.
