Bently Nevada 330106-05-30-05-12-05 3300 XL 8 mm Reverse Mount Proximity Probe

Hanya 6 item tersisa di stok

Produsen: Bently Nevada
Nomor Produk: 330106-05-30-05-12-05
Negara asal:Amerika Serikat
Jenis Produk: 3300 XL 8 mm Reverse Mount Probes
Kode batang: 8537101190
Pembayaran: T/T, Western Union
Berat: 150g
Dimensi: 150 mm x 150 mm x 30 mm (H x W x D)
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

Lihat detail lengkap

Description

330106-05-30-05-12-05: 3300 XL 8 mm reverse mount proximity probe featuring metric M10 x 1 threads, 5 mm unthreaded length (Option 05), 30 mm case length (Option 30), 0.5 meter total length (Option 05), ClickLoc connector (Option 12), and CSA/ATEX/IECEx certifications (Option 05).

This probe configuration incorporates a FluidLoc cable (Option 12), which prevents process fluids and oil from migrating through the internal gaps of the cable into external environments. The reverse-mount housing allows thread installation from inside or from the opposite side of the mounting bracket, fitting tight spaces where standard front-mount options are impractical.

Features

M10 x 1 metric thread structure suitable for reverse-mount installations.
Unthreaded length of 5 mm coupled with a 30 mm overall case length.
Total physical probe length of 0.5 meters (1.6 feet).
FluidLoc cable construction blocks oil and process liquids from leaking along the cable core.
Gold-plated ClickLoc connector provides a secure connection without tools.
Agency approval Option 05 includes CSA, ATEX, and IECEx certifications for hazardous areas.

Applications

This proximity probe is used in rotating machinery protection and condition monitoring systems. Typical installations include shaft vibration, thrust position, and speed measurements on turbines, compressors, pumps, and generators across power generation, petrochemical, and oil and gas industries.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330106-05-30-05-12-05	3300 XL 8 mm Reverse Mount Proximity Probe, M10 x 1 thread
A - Unthreaded Length Option	05	5 mm unthreaded length
B - Overall Case Length Option	30	30 mm case length
C - Total Length Option	05	0.5 meter (1.6 feet)
D - Connector and Cable-Type Option	12	Miniature coaxial ClickLoc connector, FluidLoc cable
E - Agency Approval Option	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Parameter	Specification Value
Manufacturer	Bently Nevada
Part Number	330106-05-30-05-12-05
Probe Tip Diameter	8.0 mm
Thread Size	M10 x 1
Unthreaded Length	5 mm
Case Length	30 mm
Total Length	0.5 meter (1.6 feet)
Cable Type	FluidLoc coaxial cable
Cable Outer Diameter	3.94 mm
Connector Type	Miniature male coaxial ClickLoc connector
Operating Temperature	-52 degC to +177 degC
Pressure Seal Limit	Up to 10.3 bar (150 psi) differential
Weight	0.15 kg
Dimensions	150 mm x 150 mm x 30 mm (H x W x D)

Installation Guidelines

Install the probe in an M10 x 1 threaded hole or matching bracket. Maximum thread engagement for this model is 15 mm. Tighten the ClickLoc coaxial connector finger-tight until it clicks. Do not exceed the maximum torque limits for M10 threads during body mounting.

Compliance and Certifications

This product complies with major international safety standards. Option 05 specifies certifications under CSA, ATEX, and IECEx for intrinsic safety and non-incendive installations in hazardous locations.

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 Probe Proksimitas NSv 3300 XL	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 Probe Proksimitas 8 mm 3300 XL	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 Probe Proksimitas 8 mm 3300 XL	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Reverse Mount Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the FluidLoc cable option (Option 12) do for this probe?

The Option 12 FluidLoc cable prevents oil, water, or other process fluids from leaking out of the machine housing through the internal spaces of the probe cable.

How does a reverse mount probe differ from a standard probe?

Reverse mount probes like this M10 x 1 model are threaded through the mounting bracket or housing from the opposite side, which is useful when clearance or mounting space is restricted.

What is the total length of the 330106-05-30-05-12-05 probe?

The total length of this configuration is 0.5 meters (1.6 feet) as specified by Option 05.

Which hazardous area approvals does Option 05 provide?

Option 05 provides approvals from major agencies including CSA, ATEX, and IECEx for hazardous environments.
