Modul Input DC Jaringan Lapangan CC-Link IE Mitsubishi Electric NZ2GF2B1N-16D

Description

Designed for seamless integration into high-speed automation networks, the NZ2GF2B1N-16D serves as a reliable CC-Link IE Field Network remote digital input block. This module enables efficient data acquisition by interfacing field sensors directly with a centralized controller over industrial Ethernet. Featuring a 16-point digital input capacity, it provides flexible configuration options for positive or negative common wiring schemes, optimizing it for diverse sensor types in modern manufacturing environments.

The physical design of the NZ2GF2B1N-16D highlights operational efficiency and maintenance simplicity. It utilizes a two-piece screw terminal block, allowing maintenance personnel to replace the electronic module without disconnecting the field wiring, thereby minimizing system downtime. Utilizing a highly efficient 1-wire connection scheme, it reduces panel wiring complexity while maintaining high signal integrity and noise immunity under demanding industrial conditions.

Features

• High-Speed Communication: Designed specifically as a slave station for the high-bandwidth CC-Link IE Field Network.
• Efficient Field Wiring: 1-wire connection type simplifies layout design and reduces installation labor.
• Two-Piece Terminal Block: Detachable screw-type connection allows module replacement without disturbing existing wiring.
• Flexible Input Configuration: Supports both positive common and positive/negative shared common connections.
• Robust Physical Build: Compact block-type remote module designed for DIN-rail or panel-mount enclosures.

Applications

• Automotive assembly lines and conveyor systems
• Water and wastewater processing plants
• Packaging machinery and material handling equipment
• General factory automation and multi-axis assembly systems

Technical Specifications

Installation Guidelines

• Mounting: Securely mount the module on a standard 35mm DIN rail or directly to an electrical enclosure backplane using appropriate screws.
• Wiring: Ensure all terminal screws are torqued to the manufacturer-specified values to prevent loose connections or high-resistance contact.
• Grounding: Connect the protective earth (PE) terminal to the functional ground of the control panel using a low-impedance conductor to ensure optimal noise suppression.
• Thermal Management: Maintain adequate clearance around the module vents to facilitate natural convection and prevent heat buildup within the enclosure.

Compliance and Certifications

• CE Compliant
• UL / cUL Listed
