This two-wire, loop-powered device is designed to interface with a non-contacting 3300 NSv proximity probe and its matching extension cable. The 990-05-50-02-00 conditions the incoming proximity sensor signal into appropriate peak-to-peak vibration amplitude engineering units, converting it into a proportional 4 to 20 mA industry-standard current loop output. This analog output is transmitted directly to a machinery control system, such as a PLC or DCS, where standard protection alarming and machinery logic are performed.
The unit integrates the functionality of a Proximitor Sensor directly into its housing, requiring no separate external driver. It features a non-isolated PROX OUT coaxial connector and terminal block connection to supply a dynamic vibration and gap voltage signal for troubleshooting and machinery diagnostic operations. Built with potted construction, the device provides robust environmental protection suitable for highly humid or condensing locations.
| Model | Full-Scale Option (AA) | System Length Option (BB) | Mounting Option (CC) | Agency Approval Option (DD) |
|---|---|---|---|---|
|
990-05-50-02-00
|
05 (0-5 mils pp / 0-125 um pp) | 50 (5.0 meters / 16.4 feet) | 02 (Bulkhead screws) | 00 (Not required) |
Specifications apply at +22 Celsius (+72 Fahrenheit) using a 3300 NSv Probe and Extension Cable, and an AISI 4140 steel target unless specified otherwise.
| Category | Parameter | Specification Values |
|---|---|---|
| Electrical / Power | Input Requirements | +12 to +35 Vdc input at the transmitter terminal |
| Signal Output | 4 to 20 mAdc over specified full-scale range (2-wire configuration) | |
| Loop Accuracy | Within ±1.5% over specified full-scale range across 250 Ohm loop resistance | |
| Maximum Loop Resistance | 1,000 Ohm including cable at 35 Vdc | |
| Current Limiting | 23 mA typical | |
| Power-up Inhibit | Signal output stays below 3.6 mA for 2 to 3 seconds after power application | |
| Dynamic Output | Prox Out Linear Range | 1.4 mm (55 mils), starting approx 0.25 mm (10 mils) from target surface |
| Incremental Scale Factor | 7.87 mV/um (200 mV/mil) ±6.5% typical | |
| Output Impedance | 10 kOhm output impedance calibrated for a 10 MOhm load | |
| Frequency Response | 5 Hz to 6,000 Hz +0, -3 dB | |
| Typical Noise Level | 50 mV pp | |
| Environmental Limits | Operating Temperature | -35 Celsius to +85 Celsius (-31 Fahrenheit to +185 Fahrenheit) |
| Storage Temperature | -52 Celsius to +100 Celsius (-62 Fahrenheit to +212 Fahrenheit) | |
| Relative Humidity | 100% condensing, non-submerged (requires coaxial connector protection) | |
| Mechanical | Transducer Tip Material | Polyphenylene sulfide (PPS) |
| Transducer Case Material | AISI 303 or 304 Stainless Steel (SST) | |
| Transmitter Weight | 0.43 kg (0.9 lbm) | |
| Total System Weight | 0.82 kg (1.8 lbm) typical | |
| Dimensions | 100.1 mm x 73.9 mm x 42.6 mm (3.94 in x 2.91 in x 1.68 in) | |
| General | Manufacturer | Bently Nevada (A Baker Hughes Company) |
| Country of Origin | United States | |
| Target Requirements | Minimum 9.5 mm (0.375 in) diameter, AISI 4140 steel target |
| Terminal / Connector | Function |
|---|---|
| Terminal E1 | Power Supply (+) / 4 to 20 mA loop input |
| Terminal E2 | Power Supply (-) / Loop return connection |
| Terminal E3 | PROX OUT dynamic signal terminal |
| Terminal E4 | COM terminal reference for PROX OUT |
| J2 BNC Connector | Coaxial PROX OUT dynamic transducer signal for portable diagnostics |
| J3 Coaxial Interface | Input connection from the 3300 NSv proximity probe extension cable |
What is the behavior of the output loop current when a proximity probe is damaged or disconnected?
The transmitter is equipped with an internal Not OK and Signal Defeat circuit. If a faulty probe or open connection is experienced, the loop output current automatically drops to less than 3.6 mA within 100 microseconds to suppress false machine alarms in the control system.
Can I run standard plant diagnostic software using the 4 to 20 mA output of this transmitter?
The 4 to 20 mA signal provides overall peak-to-peak trending data only and is not compatible with plant-wide dynamic diagnostic systems like System 1. The analog output cannot determine the phase of vibration or handle specialized parameters like gap alarms or Trip Multiply.
Why is an external test adapter required when connecting an oscilloscope to the PROX OUT terminal?
The PROX OUT signal shares a common ground reference with the non-isolated 4 to 20 mA loop current. Connecting grounded, AC-powered diagnostic tools directly to the transmitter can alter the loop current and cause accidental machinery shutdowns, so an isolating test adapter must be used
