Allen-Bradley

Allen-Bradley 80190-600-01-R PowerFlex 7000 Optical Interface Base Board

SKU Allen Bradley 80190-600-01-R

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Allen-Bradley
  • Product No.: Allen Bradley 80190-600-01-R
  • Origin United States
  • Product Type: Optical Interface Base Board
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.32 kg
  • Dimensions: 25.1cm x 19cm x 2.6cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Optical Interface Boards Powerflex 7000
Quantità
Call sales Contact

Product Description

The Allen-Bradley 80190-600-01-R is a Packaged Customer Optical Interface Base Board (OIBB) Assembly designed for control isolation and signal distribution within medium voltage drive topologies. This hardware assembly serves as a foundational Optical Interface Base Board that routes high-speed fiber-optic data channels between core drive processing circuitry and localized gate driver systems. By converting electrical logic commands into optical paths, the 80190-600-01-R establishes critical galvanic separation between high-voltage power paths and low-voltage control layers, optimizing overall system noise immunity and timing synchronization.

Features

  • Secure fiber-optic transceiver mounting connections
  • Native integration paths with primary drive processor modules
  • Multilayer trace pathways for stable power distribution and signal processing
  • Rigid circuit board structure optimized for medium voltage drive enclosures

Applications

  • PowerFlex 7000 Medium Voltage AC Drive control architectures
  • High-voltage isolation interface networks
  • Synchronous optical signal distribution assemblies

Technical Specifications

Parameter Specification
Manufacturer Allen-Bradley / Rockwell Automation
Part Number 80190-600-01-R
Component Type Optical Interface Base Board (OIBB) Assembly
System Compatibility PowerFlex 7000 Series

Installation Guidelines

  • Static Control Measures: This electronic assembly incorporates highly static-sensitive components. Use an approved, grounded static-dissipative wrist strap and an ESD-protected mat throughout all handling and mounting phases.
  • Lockout-Tagout Protocols: Disconnect and completely isolate all primary medium voltage inputs and auxiliary power linkages feeding the cabinet. Ensure full discharge of the DC link capacitors before executing board installation.
  • Fiber-Optic Care: Avoid bending fiber-optic cable connections past the specified minimum radius parameters during installation to prevent internal attenuation or signal breakage at the board interface terminals.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the device?
The device serves as a specialized base board for managing optical signal channels, establishing necessary electrical isolation between the main control processor and high-power firing circuits.
Which specific equipment family uses this optical base board?
The assembly is designed exclusively for deployment inside Allen-Bradley PowerFlex 7000 Medium Voltage AC Drive systems.
What handling procedures are recommended during installation?
Field engineers must employ strict ESD grounding procedures, isolate all input power sources, and avoid structural over-bending of connected fiber-optic cables.
