Product Overview

The B&R X20DS4389 (X20 DS 4389) is a high-precision digital signal processor module designed for the B&R X20 automation system. Engineered for applications requiring extreme speed and microsecond-level accuracy, this module is ideal for tasks such as registration mark detection, pulse duration measurement, and high-speed motion sequence generation. By decoupling signal processing from the standard X2X Link cycle time through integrated timestamp and oversampling technology, it provides high-fidelity control in high-speed manufacturing, assembly, and packaging environments.

Technical Configuration

The X20DS4389 features a highly flexible I/O architecture:

• 4 Dedicated Digital Inputs: Designed for 24 VDC operation with high-speed response.
• 4 Configurable Channels: Can be independently set as either digital inputs or outputs to suit specific application needs.
• NetTime Support: Integrated timestamping with 125 ns resolution, allowing for precise event tracking regardless of bus communication latency.
• Oversampling Capability: Enables the acquisition and generation of signal patterns with durations shorter than the X2X Link cycle time (up to 25 µs scan rates).
• Edge Detection: Each of the 4 units supports pulse duration/differential time measurement and includes history buffers for event logging.

Technical Specifications

FAQs

What are the primary industrial applications for this module?

The X20DS4389 is used in automation tasks that require high-speed precision, such as high-speed sorting, registration mark sensing on packaging lines, and precise timing for drum sequencers or industrial actuators.

How does the timestamp function improve performance?

The integrated timestamp function records the exact time an input edge occurs with 125 ns resolution. This allows the controller to react to high-speed events that might otherwise be missed or suffer from "jitter" caused by standard bus cycle fluctuations.

Are accessories included?

No, this module requires the X20TB12 terminal block and X20BM11 bus module for installation. These must be ordered separately.

Installation and Operational Guidelines

• Wiring and Signal Integrity: Given the high-speed nature of the signals handled by this module (up to 40 kHz), always utilize shielded cabling. Keep signal cables separate from high-power AC or DC motor lines to prevent electromagnetic interference from triggering false edge detection.
• Grounding: The 24 VDC and GND connections must be robust. Ensure that the sensor/actuator supply is clean and stable, as noise on the power rail can affect the high-precision timing of the NetTime functions.
• Configuration: Utilize the B&R software suite to configure the operating modes (oversampling, edge detection, or timestamping) for the specific channel requirements. Ensure the software settings match the hardware physical connections to prevent logic errors.
