Description

Engineered to handle demanding control, visualization, and human-machine interface tasks in harsh manufacturing environments, the Beckhoff CP6501-0001-0080 is a high-performance built-in Panel PC designed for seamless control cabinet integration. This unit features an integrated 12-inch TFT display with an 800 x 600 pixel resolution, offering clear visual feedback for industrial software applications. Housed in a heavy-duty, 7-slot ATX enclosure, the system balances computing power with extensive physical expansion options, making it a reliable engine for complex automated lines and factory systems.

The display panel is designed for front-mounting installations, utilizing a specialized clamping mechanism that ensures a secure, dust-tight, and moisture-resistant fit. Inside, the device supports high-speed processing and networking, including dual onboard gigabit Ethernet interfaces and multiple expansion slots for specialized communication or industrial I/O cards. This makes it highly compatible with Beckhoff TwinCAT control software and standard fieldbus environments.

Features

• High-contrast 12-inch TFT display with 800 x 600 resolution for clear industrial visualization.
• Robust 7-slot ATX housing design supporting a wide range of PCI and PCIe expansion boards.
• Fast, tool-free installation assisted by integrated pull-out clamping levers.
• Dual 100/1000BASE-T onboard Ethernet connections for reliable industrial network communication.
• Industrial-grade front panel providing protection against dust and liquid jets.
• Durable passive and active cooling structures configured to withstand harsh operating parameters.

Applications

• Continuous process monitoring and control systems in automotive manufacturing.
• HMI and supervisory control in water and wastewater treatment facilities.
• Main operator terminal for complex packaging and material handling machinery.
• Data concentration and gateway processing on production plant floors.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Ensure the panel cutout dimensions precisely match the specification requirements of the 12-inch frame.
• Insert the Panel PC into the cutout from the front and secure using the built-in pull-out clamping levers. Tighten standard mounting screws evenly to compress the front-facing IP65 seal.
• Maintain a minimum clearance of 50 mm above and below the rear ATX housing to promote adequate thermal air convection.
• Connect the functional earth terminal on the housing directly to the main cabinet ground using a low-impedance conductor.
• Ensure supply voltage lines comply strictly with the designated 100 to 240 V AC or 24 V DC input ratings prior to energizing the device.
