Description

Designed for machine-level control and visualization tasks, the BECKHOFF CP6631-0001-0020 built-in Panel PC combines a robust display unit with a highly integrated controller platform. Featuring an ARM Cortex-A8 processor running at 1 GHz, this hardware configuration provides an optimized computing platform for TwinCAT automation projects. The mechanical construction features a durable aluminum front panel paired with a sheet-steel rear cover, designed specifically for control cabinet installation.

The unit features a 12-inch TFT display with a resolution of 800 x 600 pixels. For user interaction, the front layout is equipped with a touchscreen interface, enabling intuitive navigation. Internal system storage is managed through a microSD slot, complemented by non-volatile memory (128 kByte NOVRAM) to ensure critical process data is retained during power loss events. Dual Ethernet interfaces (including an on-board EtherCAT connection) provide high-speed industrial network communication directly from the terminal.

Features

• Durable 12-inch display with 800 x 600 resolution and integrated single-finger touchscreen.
• ARM Cortex-A8 1 GHz processor optimized for low-power, fanless industrial control.
• Built-in 128 kByte NOVRAM for secure, persistent storage of retain data.
• Robust housing design featuring an aluminum front and sheet-steel rear enclosure.
• Quick-mount construction using integrated pull-out clamping levers.
• Dual network ports including standard 10/100BASE-T Ethernet and dedicated EtherCAT interfaces.

Applications

• Machine-level human-machine interface (HMI) and visualization.
• Distributed industrial control systems using EtherCAT networks.
• Factory automation, packaging machinery, and assembly line stations.
• Process monitoring and localized data acquisition in manufacturing environments.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Ensure the panel cutout dimensions match the physical specification of the CP6631 housing.
• Utilize the integrated pull-out clamping levers to secure the unit within the cabinet panel. Avoid over-tightening.
• Verify that the front-panel sealing gasket is seated flatly against the mounting surface to maintain the IP65 ingress protection rating.
• Provide a minimum clearance of 50 mm above and below the rear cover to allow natural convection airflow for thermal dissipation.
• Ensure proper functional grounding of the chassis via the designated grounding screw terminal on the rear panel.
