Description

Designed for seamless integration into control cabinet doors or operator consoles, the CP6902-0021-0000 economy built-in Control Panel delivers a robust visualization interface for industrial environments. Featuring a 15-inch display with a resolution of 1024 x 768 pixels, this high-performance industrial human-machine interface (HMI) uses integrated DVI-E (DVI Extended) and USB-E 2.0 (USB Extended) connection technology. This allows the operator panel to function at distances of up to 50 meters from the industrial PC, providing maximum layout flexibility on the factory floor.

The unit features a rugged construction comprising an aluminum front panel and a protective sheet-steel rear cover, engineered to withstand challenging industrial conditions. It is equipped with a capacitive single-finger touch screen for intuitive operator input. With high-speed USB-E 2.0 connection capabilities, data is transmitted at up to 480 Mbit/s, enabling real-time touch response and quick access to auxiliary USB ports directly from the front panel interface.

Features

• 15-inch active matrix TFT display with a sharp 1024 x 768 resolution.
• Built-in DVI-E and USB-E 2.0 connection technology for long-distance remote operation up to 50 meters.
• Robust aluminum front bezel with a heavy-duty sheet-steel rear enclosure.
• Reliable single-finger touch screen configuration for precise operator input.
• Integrated USB 2.0 hub with two external ports for peripheral connections.
• Pull-out clamping levers for efficient, toolless physical cabinet installation.

Applications

• Automotive assembly line visualization and process monitoring.
• Packaging machine control systems and operator consoles.
• Oil and gas refinery control room remote displays.
• Food and beverage processing plant automation.
• Custom test bench and laboratory monitoring stations.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting: Slide the unit into the pre-cut panel opening and secure it from the rear using the built-in, pull-out clamping levers. Tighten the clamping screws evenly to ensure correct IP65 sealing on the front surface.
• Cabling Constraints: For lengths exceeding 5 meters, ensure a verified Beckhoff USB-E 2.0 and DVI-E transmitter module is utilized at the host PC end. Do not exceed the maximum transmission limit of 50 meters.
• Grounding: Connect the functional earth terminal on the rear of the steel housing directly to your control cabinet's main grounding busbar using a low-impedance conductor.
• Thermal Management: Maintain a minimum clearance of 50 mm above, below, and behind the unit to allow natural convection cooling. Ensure ambient environment remains within 0 to 55 degC.
