Description

The BECKHOFF CP7203-0001-0060 is an industrial Economy Panel PC engineered for mounting arm installation in demanding control environments. Housed in a durable aluminum casing, this terminal provides comprehensive IP65-rated ingress protection, making it highly resilient against dust and moisture. It is designed to act as a centralized operator control and visualization interface directly at the machine or process line.

Equipped with a 19-inch display featuring a resolution of 1280x1024 pixels, the BECKHOFF CP7203-0001-0060 incorporates a single-finger touch screen for reliable operator inputs. Performance is driven by an Intel Celeron G3900TE 2.3 GHz dual-core processor on a 3.5-inch motherboard, supported by 4 GB of DDR4 RAM. The unit provides specialized cooling using a heat sink structure paired with an internal fan to distribute thermal loads evenly across the outer housing walls.

Connectivity is highly configurable, featuring a dedicated wiring area that supports up to six IP65 connectors, including a pre-routed 100/1000BASE-T Ethernet interface. Storage capabilities include a 2.5-inch slot populated with a 320 GB hard disk, alongside a dedicated CFast slot, providing ample flexibility for control software, operating systems, and localized data logging.

Features

• 19-inch high-resolution display (1280x1024) with a reliable single-finger touch sensor.
• Intel Celeron G3900TE 2.3 GHz dual-core processor matching TwinCAT performance class 50 requirements.
• Durable aluminum housing designed specifically for top-mounted, rotatable mounting arm configurations.
• Integrated passive heat-sink cooling design assisted by an internal air-circulation fan.
• Dual storage expansion options with a dedicated 2.5-inch drive bay and a CFast card slot.
• IP65-rated wiring area providing protection for up to six industrial connectors.

Applications

• Machine-level visualization and human-machine interface (HMI) operations.
• Suspended mounting arm operator stations in production lines and assembly areas.
• Industrial process monitoring requiring high environmental protection ratings.

Technical Specifications

General

Processing and Memory

Display and User Interface

Electrical and Environmental

Installation Guidelines

1. Verify that the mounting arm system matches the required 48 mm tube installation standard.
2. Ensure all power distribution sources are fully isolated and de-energized before mounting.
3. Attach the Panel PC securely to the mounting arm using the integrated rotatable adapter from the top.
4. Ensure a minimum clearance of 20 cm (7.9 inches) around all sides of the aluminum housing to permit proper passive heat dissipation.
5. Connect the 24 V DC power supply to the unit, paying close attention to correct terminal assignments and polarity.
6. Route all communication and signal cables through the designated IP65 wiring area, ensuring all unused cable entry points remain sealed to protect the system's IP rating.

Replacement Recommendations

Before replacing an active operator terminal, safely shut down the control software and disconnect the main 24 V DC supply. Document all network settings, IP configurations, and physical cabling connections. Carefully transfer the existing storage configurations, such as the CFast card or 2.5-inch drive, to the replacement BECKHOFF CP7203-0001-0060 unit. Ensure that all IP65 connectors and structural gaskets are checked and properly seated during re-assembly to protect the internal electronics from moisture.
