BECKHOFF CU8803-0000 CP-Link 4 Transmitter Box

SKU CU8803-0000

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: CU8803-0000
  • Origin Germany
  • Product Type: Transmitter Boxes
  • Payment: T/T, Western Union
  • Weight: 5.0 kg
  • Dimensions: 70 mm x 100 mm x 80 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CP-Link Transmitter Boxes
Quantità
Call sales Contact

Product Description

Description

Integrating Industrial PCs with remote Control Panels is simplified using the CU8803-0000 transmitter box, designed to implement the Beckhoff CP-Link 4 One Cable Display Link technology. This industrial hardware module enables the transmission of video signals, USB 2.0 data, and power over a single Cat.6A connection up to 100 meters away from the host PC.

By routing power directly through the connection, the CU8803-0000 transmitter box eliminates the need for a secondary local power supply at the operator terminal, streamlining system architecture and reducing field wiring costs. The unit connects directly to the PC’s standard DVI-D and USB-B ports and converts these signals for transport over a standardized RJ45 network cable.

Features

  • Transmits DVI-D, USB 2.0 (up to 100 Mbit/s), and 24 V DC operating power over a single cable.
  • Supports distances up to 100 meters utilizing Cat.6A infrastructure.
  • Direct integration with PC interfaces via standard 1-meter connection cables (included).
  • Compact, rugged metal housing designed for DIN rail mounting (IP20 protection).
  • Built-in LED indicators for fast diagnostic verification of link status.

Applications

  • Remote operator terminal connection in manufacturing plants.
  • Machine tool and packaging line control where operator panels are positioned far from the control cabinet.
  • Explosion-hazardous environments requiring remote panel mounting via certified transmitter interfaces.

Technical Specifications

Manufacturer BECKHOFF
Part Number/Model CU8803-0000
Device Type CP-Link 4 Transmitter Box (One Cable Display Link)
Input Interfaces 1 x DVI-D socket, 1 x USB Type B socket
Output Interfaces 1 x CP-Link 4 (RJ45 socket)
Input Connection Cables (Included) 1 m DVI to DVI cable, 1 m USB-A to USB-B cable
Maximum Range Up to 100 m (Cat.6A cable)
Power Supply Input 24 V DC
Operating Temperature 0 to +55 degC
Protection Rating IP20
Dimensions (W x H x D) 70 mm x 100 mm x 80 mm
Shipping Weight 5.0 kg

Installation Guidelines

  • Mounting: Mount horizontally on a standard 35 mm DIN rail within a clean, dry control cabinet.
  • Cabling: Maintain input cable lengths (DVI and USB) under 1 meter. Only use certified Cat.6A cables for the CP-Link 4 connection to guarantee performance over longer runs.
  • Grounding: Ensure the DIN rail is properly grounded to mitigate electromagnetic interference on the communication lines.
  • Thermal Management: Maintain at least 50 mm of free space above and below the device to ensure natural convection cooling.

Compliance and Certifications

  • CE
  • ATEX: II 3 G Ex nA IIC T4 Gc, II 3 D Ex tc IIIC T135 degC Dc
  • IECEx: (Requires optional adapter C9900-Z484)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Beckhoff CU8803-0000?
The CU8803-0000 is a CP-Link 4 transmitter box that allows you to connect a Beckhoff Control Panel to an industrial PC up to 100 meters away, transmitting video, USB 2.0, and power over a single Cat.6A cable.
Does the CU8803-0000 supply power to the connected Control Panel?
Yes, it transmits 24 V DC operating power directly to the Control Panel through the CP-Link 4 connection, eliminating the need for a separate power line at the display.
What cables are included with the CU8803-0000 transmitter box?
The package includes a 1-meter DVI-to-DVI cable and a 1-meter USB-A to USB-B cable to connect the transmitter box to the host PC.
Can the CU8803-0000 be used in hazardous locations?
Yes, the transmitter carries ATEX and IECEx (with optional C9900-Z484 accessory) certifications for Zone 2/22 environments.
