BECKHOFF CX2042-N031-0002 CX2000 Embedded PC Basic CPU Module

SKU CX2042-N031-0002

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: CX2042-N031-0002
  • Origin Germany
  • Product Type: Embedded PCs
  • Payment: T/T, Western Union
  • Weight: 3.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CX2000 Embedded PCs
Quantità
Call sales Contact

Product Description

Description

Designed for demanding, high-performance automation tasks, the CX2042-N031-0002 serves as a robust basic CPU module within the modular Beckhoff CX2000 Embedded PC family. Utilizing multi-core processing power, this industrial controller is engineered to handle complex TwinCAT real-time control, PLC, NC, and CNC applications with high precision. This specific hardware variant integrates the -N031 system interface option, providing an RS485 serial communication port configured via a 9-pin D-sub socket. Engineered as a drop-point configuration without echo and with termination switched off, it allows for direct integration with legacy serial devices and serial fieldbus systems within the cabinet.

Features

  • Equipped with high-performance multi-core processing architecture for real-time automation.
  • Integrated -N031 interface providing a dedicated RS485 communication channel.
  • 9-pin D-sub interface configured as a drop point (no echo, termination disabled) for direct network integration.
  • Modular expandability via direct connection to EtherCAT Terminals (EL/ES) or Bus Terminals (KL/KS).
  • Robust, industrial-grade housing designed to withstand vibration and temperature fluctuations in control environments.

Applications

  • Complex CNC, PLC, and motion control systems in manufacturing.
  • Central control nodes for distributed fieldbus networks.
  • Industrial process monitoring and data acquisition systems.
  • Upgrade paths for legacy installations requiring RS485 serial integration.

Technical Specifications

Manufacturer Beckhoff Automation
Part Number / Model CX2042-N031-0002
Series CX2000 Embedded PC
Module Type Basic CPU Module
Interface Option -N031 (RS485 interface)
Connection Type 9-pin D-sub socket
Interface Configuration Drop point, without echo, termination off
System Bus Connection Direct connection to Beckhoff I/O terminals (EtherCAT)
Shipping Weight 3.0 kg

Connections and Interfaces

Interface Type Specification / Pinout Configuration Settings
RS485 9-pin D-sub female socket Drop point configuration
Echo Mode Disabled (Without echo) Internal loopback off
Termination Switched Off External termination required if acting as network end-node

Installation Guidelines

  • Mounting: Snap onto standard 35 mm DIN rail (EN 60715) within a horizontal installation position.
  • Ventilation: Maintain standard physical clearance above and below the CPU module to facilitate heat dissipation.
  • Grounding: Ensure a low-impedance electrical connection between the CPU module backplane and the DIN rail.
  • Shielding: Use high-quality shielded twisted-pair (STP) cabling for the RS485 interface to prevent electromagnetic interference (EMI).
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the function of the -N031 option on the CX2042-N031-0002?
The -N031 option integrates an RS485 system interface via a 9-pin D-sub socket. It is configured as a drop point with no echo and with termination switched off.
Can I connect standard EtherCAT Terminals directly to this CPU?
Yes, the CX2042 series CPU modules support direct connection of Beckhoff EtherCAT Terminals (EL/ES series) through the integrated system bus.
Does the RS485 interface on this module have internal termination enabled?
No, the serial interface on this module is configured with the termination switched off.
