BECKHOFF CX5240-B110 Embedded PC

SKU CX5240-B110

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: CX5240-B110
Origin Germany
Product Type: Embedded PCs
Payment: T/T, Western Union
Weight: 1.195 kg
Dimensions: 142 mm x 100 mm x 92 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF CX5240-B110 is an embedded PC designed for mid-range control applications. Powered by an Intel Atom processor with 4 cores running at 1.6 GHz, this compact DIN-rail mountable controller offers high-performance capabilities within the TwinCAT 3 environment (Performance Plus platform level 50). The system provides a compact footprint for decentralized or centralized machine automation, combining processing power, communication interfaces, and direct I/O terminal connectivity into a single unit.

This embedded controller is equipped with 8 GB of internal DDR4 RAM and features dual storage interfaces, including slots for both CFast and microSD cards. To protect critical operational data during unexpected power failures, the device incorporates an integrated 1-second UPS that retains up to 1 MB of persistent data on the CFast card.

The BECKHOFF CX5240-B110 features high adaptability with an integrated I/O interface that automatically recognizes and supports both E-bus (EtherCAT) and K-bus (Bus Terminal) systems. This allows direct connection of terminal blocks without additional bus couplers, optimizing assembly space and engineering flexibility.

Features

Intel Atom x5-E3930 processor (1.6 GHz, 4 cores) for industrial execution speeds
8 GB internal DDR4 RAM for program and system execution
Dual storage expansion slots supporting CFast and microSD cards
Integrated 1-second UPS with 1 MB persistent memory capability on CFast
Automatic recognition and direct connection of Beckhoff E-bus and K-bus I/O systems
Dual RJ45 Gigabit Ethernet ports (10/100/1000 Mbit/s) for high-speed network communication
Exchangeable internal battery-backed real-time clock

Applications

Medium-scale machine automation and manufacturing system control
Decentralized control installations requiring direct connection of EtherCAT or Bus Terminals
Industrial edge processing, data acquisition, and gateway applications
Modernization of legacy systems utilizing mixed K-bus and E-bus architectures

Technical Specifications

Parameter	Specification
Manufacturer	BECKHOFF
Model	CX5240-B110
Processor	Intel Atom x5-E3930, 1.6 GHz, 4 cores
Main Memory	8 GB DDR4 RAM (internal, non-expandable)
Flash Memory	Slots for CFast card and microSD card (cards not included)
Persistent Memory	Integrated 1-second UPS (1 MB on CFast card)
I/O Connection	E-bus (EtherCAT) or K-bus (Bus Terminal), automatic recognition
Interfaces	2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-D, 4 x USB 3.0, 1 x optional interface
Diagnostics LEDs	1 x power, 1 x TC status, 1 x flash access, 2 x bus status
Clock	Internal battery-backed clock for time and date (battery exchangeable)
Power Supply	24 V DC (-15% / +20%)
Electrical Isolation	Yes
Max. Power Consumption	18 W (34 W when charging UPS)
TwinCAT 3 Platform Level	Performance Plus (50)
Dimensions (W x H x D)	142 mm x 100 mm x 92 mm
Weight	Approx. 1195 g
Protection Rating	IP20
Operating Temperature	-25 to +60 degC
Storage Temperature	-40 to +85 degC
Relative Humidity	95%, non-condensing
EMC Immunity/Emission	Conforms to EN 61000-6-2 / EN 61000-6-4
Vibration/Shock Resistance	Conforms to EN 60068-2-6 / EN 60068-2-27
Approvals/Markings	CE, UL

Installation Guidelines

Ensure that the entire control cabinet is completely de-energized before mounting.
Mount the CX5240-B110 horizontally onto a standard 35 mm DIN rail (EN 60715) ensuring adequate airflow around the cooling ribs.
Insert the configured CFast and/or microSD card into their respective slots before powering up the system.
Connect the 24 V DC power supply line, respecting polarity and grounding requirements.
Attach the required Beckhoff E-bus or K-bus terminals directly to the right side of the unit; the system will automatically recognize the connected bus type upon startup.
Verify all interface connections (Ethernet, DVI-D, and USB) are secure and routed correctly to prevent mechanical stress on the ports.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What processor is used in the BECKHOFF CX5240-B110?

The BECKHOFF CX5240-B110 Embedded PC is equipped with an Intel Atom x5-E3930 processor running at 1.6 GHz with 4 cores, corresponding to TwinCAT 3 platform level 50.

Does the BECKHOFF CX5240-B110 require separate K-bus or E-bus modules?

No, the BECKHOFF CX5240-B110 features an automatic recognition system that can interface directly with either E-bus (EtherCAT Terminals) or K-bus (Bus Terminals) attached to the right side of the controller.

How does the integrated UPS on the BECKHOFF CX5240-B110 handle power failure?

The BECKHOFF CX5240-B110 features an integrated 1-second UPS that provides sufficient power to store up to 1 MB of persistent data onto the CFast card during an unexpected loss of input voltage.

Is the main memory on the BECKHOFF CX5240-B110 upgradeable?

No, the BECKHOFF CX5240-B110 is built with 8 GB of internal DDR4 RAM that is integrated directly onto the system board and cannot be expanded.

What storage cards are compatible with the BECKHOFF CX5240-B110?

The BECKHOFF CX5240-B110 features two slots designed for a CFast card and a microSD card. Please note that these memory cards are not included with the unit and must be ordered separately.
