The EJ2809 is a high-density 16-channel digital output module from the Beckhoff EtherCAT plug-in module series. Designed for integration into application-specific I/O systems, this module facilitates direct, component-level connection to backplane boards. It supports 24 V DC applications and is capable of driving ohmic, inductive, and lamp loads with a maximum current of 0.5 A per channel. The module features robust electrical isolation between the E-bus and field potential, ensuring high-speed data reliability and system safety within compact automation assemblies.
| Feature | Specification |
|---|---|
| Manufacturer | Beckhoff |
| Number of Outputs | 16 |
| Nominal Voltage | 24 V DC (-15 %/+20 %) |
| Max. Output Current | 0.5 A per channel |
| Short-Circuit Current | Typ. < 2 A |
| E-bus Consumption | Typ. 110 mA |
| Electrical Isolation | 500 V (E-bus/field potential) |
| Dimensions (Weight) | Approx. 30 g |
| Protection Rating | IP20 |
| Approvals | CE, UL |
