BECKHOFF EPI1008-0002 IO-Link Box

SKU EPI1008-0002

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: EPI1008-0002
Origin Germany
Product Type: IO-Link box
Payment: T/T, Western Union
Weight: 0.5 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

The EPI1008-0002 is a compact 8-channel digital input IO-Link box by BECKHOFF, designed for decentralized signal acquisition in industrial environments. Utilizing the IO-Link V1.1 (Class A) standard, this module enables efficient communication between field-level sensors and higher-level automation controllers. With a robust IP65/66/67-rated housing, the EPI1008-0002 is built to withstand harsh conditions, offering high ingress protection and reliable performance in distributed I/O architectures.

Features

8 digital input channels for 24 V DC signals
IO-Link communication (V1.1, Class A) with 230.4 kbaud (COM 3) transfer rate
Adjustable input filter (default 3.0 ms, range 0–20 ms)
Short-circuit-proof sensor supply (max. 0.5 A)
Rugged IP65/66/67 protection rating
Wide operating temperature range: -25 to +60 degC
M12 connection technology for field-ready installation

Applications

Distributed sensor monitoring in manufacturing systems
Industrial automation tasks requiring high ingress protection
Parameterization and diagnostic-heavy sensor integration via IO-Link
Modular machine control systems

Technical Specifications

Category	Specification
Manufacturer	BECKHOFF
Model	EPI1008-0002
Communication Protocol	IO-Link V1.1 (Class A)
Number of Inputs	8
Nominal Input Voltage	24 V DC (-15 %/+20 %)
Input Filter	3.0 ms (default), 0 to 20 ms adjustable
Input Current	typ. 3 mA
Sensor Supply	max. 0.5 A (total)
Operating Temperature	-25 to +60 degC
Storage Temperature	-40 to +85 degC
Protection Rating	IP65/66/67
Weight	approx. 165 g

Connections/Interfaces

Interface Type	Function
M12 (A-coded)	IO-Link Communication
M12 (Screw type)	8-channel digital input interface

Installation Guidelines

Mount the box on a secure, vibration-resistant surface using the integrated mounting holes.
Ensure all M12 connectors are properly tightened to maintain the IP65/66/67 protection rating.
Connect the IO-Link master interface via the A-coded M12 connector.
If specific signal debouncing is required, configure the input filter via the IO-Link master software within the 0–20 ms range.
Ensure the ambient temperature remains within -25 to +60 degC for sustained operational reliability.
Adhere to EMC standards EN 61000-6-2/EN 61000-6-4 by utilizing appropriate shielded cabling.

Compliance and Certifications

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What IO-Link standard does this device support?

The EPI1008-0002 supports IO-Link V1.1, Class A.

Can the input filter be adjusted?

Yes, the input filter is adjustable from 0 to 20 ms, with a default setting of 3.0 ms.

Is the sensor power supply protected?

Yes, the sensor supply is short-circuit proof with a maximum total output of 0.5 A.

What is the IP rating for this box?

It is rated IP65/66/67, conforming to EN 60529 for dust and water resistance.
