The EPP1008-0001 (EPP1008-0001) is a robust 8-channel digital input module engineered for demanding field-level automation. Designed to withstand harsh industrial environments such as automotive production lines, packaging machinery, and material handling systems, this EtherCAT P Box ensures reliable signal acquisition directly at the machine process. By integrating high-density I/O capabilities with IP65/66/67 protection ratings, it minimizes the need for centralized control cabinets and significantly reduces cabling complexity, thereby decreasing installation time and associated system downtime.
This module utilizes the high-speed EtherCAT protocol, featuring an M8 bus interface for secure, vibration-resistant connectivity. The eight digital inputs comply with EN 61131-2 Type 3 standards, accepting a nominal 24 VDC supply. The hardware architecture incorporates a 3.0 ms input filter to suppress electrical noise and ensure signal integrity in electromagnetically dense environments. The internal electronics are housed in a durable polyamide (PA6) enclosure, providing excellent mechanical strength and environmental resistance. Power to connected sensors is derived directly from the EtherCAT P control voltage, with a short-circuit-proof capacity of up to 0.5 A, streamlining the power distribution architecture within the field-bus network.
| Feature | Specification |
| Model | EPP1008-0001 |
| Brand | BECKHOFF |
| Inputs | 8 x Digital Input |
| Interface | 2 x M8 Bus Socket (P-coded) |
| Input Voltage | 24 VDC (-15% to +20%) |
| Input Filter | 3.0 ms |
| Protection Rating | IP65/66/67 |
| Operating Temp | -25 to 60 deg C |
| Weight | Approx 165 g |
| Dimensions | 30 mm x 126 mm x 26.5 mm |
| Mounting | 2 x 3.5 mm holes for M3 screws |
What are the primary advantages of using EtherCAT P for this module?
EtherCAT P combines communication and power distribution into a single cable, reducing the number of connectors and cable runs required in the field.
Are the input channels suitable for high-speed switching?
The EPP1008-0001 includes a 3.0 ms hardware input filter, which is optimized for standard industrial sensors and switches; it is not intended for high-speed pulse capturing applications.
Can this module be mounted in any orientation?
Yes, the module is rated for variable installation positions, provided that the cable entry points are properly secured to maintain the IP65/66/67 seal.
How does the sensor power protection function?
The module features a total short-circuit-proof output current of 0.5 A for all connected sensors, preventing damage to the module in the event of a field-side wiring fault.
Environmental Sealing: To maintain the IP65/66/67 rating, ensure all unused M8 ports are fitted with appropriate screw-on protective caps. Verify that all connection cables are fully seated and tightened according to standard M8 torque specifications to prevent moisture ingress.
Vibration Resistance: Given the module's compliance with EN 60068-2-6, it is suitable for direct mounting on moving machine parts. Use M3 screws with appropriate vibration-resistant washers for the two fixing points to prevent loosening during high-cycle operations.
Signal Integrity: When routing EtherCAT P lines near power cables, ensure a minimum separation distance or use shielded conduits to adhere to EN 61000-6-2/4 standards. Although the module is shielded, consistent grounding of the mounting surface can further improve immunity against external electrical noise.
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: EPP1008-0001
Country of origin:Germany
Product Type: EtherCAT P Box
Payment: T/T, Western Union
Weight: 500g
Dimensions: 30 mm x 126 mm x 26.5 mm
Shipping port: Xiamen
Warranty: 12 months
