Beckhoff EPP2816-0008 EtherCAT P Box

SKU EPP2816-0008

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: EPP2816-0008
Origin Germany
Product Type: EtherCAT P Box
Payment: T/T, Western Union
Weight: 0.5 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The EPP2816-0008 is a high-density EtherCAT P Box module designed for industrial automation, offering 16 digital outputs. Specifically engineered to streamline connectivity for multi-pin valve terminals, this module features a 25-pin D-sub output connection. It operates over the EtherCAT protocol, supporting distributed clocks for high-precision synchronization. The module is housed in an IP65/66/67-rated enclosure, making it ideal for decentralized installation in demanding, harsh industrial environments.

Features

16 Digital Outputs via 25-pin D-sub connection
EtherCAT P protocol integration (combining communication and power)
Optimized for multi-pin connector valve terminals
Distributed clocks support for precise synchronization
Robust IP65/66/67 industrial protection
Short-circuit proof outputs (0.5 A per channel)
Wide operating temperature range: -25 degC to +60 degC

Technical Specifications

Feature	Specification
Manufacturer	Beckhoff
Protocol	EtherCAT P
Number of Outputs	16
Connection Type	D-sub socket, 25-pin, UNC4-40
Max. Output Current	0.5 A per channel (∑ 3 A)
Nominal Voltage	24 V DC (-15 %/+20 %)
Bus Interface	2 x M8 socket, P-coded
Electrical Isolation	500 V
Dimensions	Approx. 165 g
Protection Rating	IP65/66/67
Approvals	CE, UL

Installation Guidelines

Mounting: Designed for decentralized installation directly on machine frames. Ensure secure mounting using the provided mechanical housing features.
Connectivity: Connect the 25-pin D-sub cable to the valve terminal or actuator array. Ensure the UNC4-40 screws are fully tightened to maintain environmental integrity.
Bus Connection: Utilize the P-coded M8 connectors for EtherCAT P bus communication and power supply feeding.
Power Management: Ensure the total load current (∑) does not exceed 3 A, and monitor the 0.5 A per-channel limit.
Environment: The module is rated for -25 degC to +60 degC. Ensure cables are strain-relieved and routed to avoid pinch points.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the output capacity of the EPP2816-0008?

This module provides 16 digital outputs with a capacity of 0.5 A per channel (3 A total sum current).

What is the primary application for this module?

The EPP2816-0008 is specifically optimized for multi-pin connector valve terminals.

Does this module support distributed clocks?

Yes, it supports distributed clocks for synchronized control.

What is the environmental protection rating?

The module is IP65/66/67 rated, suitable for harsh, decentralized industrial use.
