Beckhoff IP3102-B400 Fieldbus Box

SKU IP3102-B400

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: IP3102-B400
  • Origin Germany
  • Product Type: Fieldbus Boxes
  • Payment: T/T, Western Union
  • Weight: 0.35 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Fieldbus Box Fieldbus Boxes
Quantità
Call sales Contact

Product Description

Description

Designed for decentralized automation layouts, the Beckhoff IP3102-B400 is a rugged fieldbus box designed to interface peripheral signals directly at the machine level. This module eliminates the need for protective control cabinets by providing a high degree of ingress protection and robust mechanical construction. The IP3102-B400 features a dual M23 connection structure for bus communication, allowing efficient daisy-chaining of fieldbus nodes. System configuration, commissioning, and diagnostics are supported via the Beckhoff KS2000 software interface, simplifying integration within complex industrial control environments.

Features

  • Direct machine installation without protective enclosures due to high IP protection rating.
  • M23 connection interface with integrated male and female 9-pin sockets.
  • Separate M8 connections for control voltage feed and downstream distribution.
  • Software-configurable parameters using the KS2000 software tool.
  • Robust resistance to industrial vibration and mechanical shock.
  • Electromagnetic compatibility suited for heavy industrial environments.

Applications

  • Decentralized manufacturing automation and assembly lines.
  • Material handling systems and conveyor control.
  • Process plants requiring localized I/O nodes without control cabinets.
  • Machine tool manufacturing and packaging systems.

Technical Specifications

Manufacturer Beckhoff
Part Number / Model IP3102-B400
Product Type Fieldbus Box
Bus Interface 1 x M23 female socket (9-pin), 1 x M23 male socket (9-pin)
Control Voltage 24 V DC (range 20 to 29 V DC)
Power Supply Connections Feed: 1 x M8 male socket (4-pin); Downstream: 1 x M8 female socket (4-pin)
Box Supply Current 85 mA + current consumption of sensors (max. 0.5 A)
Configuration Interface Via KS2000
Operating Temperature 0 to +55 degC
Storage Temperature -25 to +85 degC
Protection Rating IP65/IP66/IP67 (conforms to EN 60529)
Vibration Resistance Conforms to EN 60068-2-6
Shock Resistance Conforms to EN 60068-2-27
EMC Immunity / Emission Conforms to EN 61000-6-2 / EN 61000-6-4
Weight approx. 350 g

Connections and Interfaces

Interface Type Connector Style Pin Count Function
Bus Input M23 Male Socket 9-Pin Incoming fieldbus signal connection
Bus Output M23 Female Socket 9-Pin Outgoing fieldbus signal to next node
Power Feed M8 Male Connector 4-Pin Control voltage supply input
Power Downstream M8 Female Connector 4-Pin Control voltage distribution to adjacent module

Installation Guidelines

  • Ensure all M23 and M8 connectors are fully tightened to their specified torque ratings to maintain the IP65/66/67 ingress protection seal.
  • Mount the unit on flat surfaces using the designated mounting holes to avoid mechanical stress on the housing.
  • Route fieldbus and power cabling away from high-voltage motor cables to minimize electromagnetic interference.
  • Ensure control voltage remains within the specified 20 to 29 V DC window to prevent logic reset or communication dropout.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Beckhoff IP3102-B400 fieldbus box?
The Beckhoff IP3102-B400 is a decentralized fieldbus module designed to connect local I/O and process signals directly at the machine level, eliminating the need for electrical cabinets.
What software is used to configure the IP3102-B400?
The module is configured using the Beckhoff KS2000 configuration software interface.
What are the protection ratings of this fieldbus box?
The IP3102-B400 conforms to protection standards IP65, IP66, and IP67 according to EN 60529, making it highly dustproof and water-resistant.
What are the power supply requirements for the module logic?
The control voltage supply requirement is 24 V DC, with a permissible operating range of 20 V DC to 29 V DC.
What type of connection interface does it use for the fieldbus?
It features a dual M23 interface layout, with one 9-pin female socket and one 9-pin male socket to support loop-through wiring.
