BECKHOFF IP3312-B510 Fieldbus Box

SKU IP3312-B510

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: IP3312-B510
Origin Germany
Product Type: Fieldbus Modules
Payment: T/T, Western Union
Weight: 0.35 kg
Dimensions: 12 x 5 x 3 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF IP3312-B510 Fieldbus Box is a decentralised industrial automation device designed for harsh industrial environments requiring high protection ratings. Operating as a CANopen fieldbus node, this unit facilitates reliable data communication and connects peripheral signals directly at the machine level without requiring a control cabinet.

Equipped with an integrated CANopen interface, the device supports automatic baud rate detection from 10 kbaud up to 1 Mbaud, along with extensive communication features including process data objects, node guarding, emergency objects, and variable mapping. Its robust IP65, IP66, and IP67 construction ensures reliable performance under demanding conditions involving moisture, dust, and mechanical stress.

Features

Integrated CANopen bus interface with a 5-pin M12 plug connection
Automatic data transfer rate detection from 10 kbaud up to 1 Mbaud
Supports up to 16 send and 16 receive CANopen process data objects (PDOs)
Configurable via the KS2000 software tool or through the controller using service data objects (SDOs)
Rugged decentralized IP65/IP66/IP67 housing for direct machine-level mounting
Flexible I/O communication types including event-driven, cyclic, synchronous, and polling modes

Applications

Decentralized machine automation without control cabinets
Conveyor and material handling systems exposed to dust and moisture
CANopen-based industrial machinery and production lines
Harsh manufacturing environments requiring high ingress protection

Technical Specifications

Parameter	Specification
Manufacturer	BECKHOFF
Exact Model	IP3312-B510
Product Type	Fieldbus Box
Bus Interface	1 x M12 plug, 5-pin
Data Transfer Rates	Automatic detection of 10 kbaud up to 1 Mbaud
Data Transfer Medium	Shielded copper cable (2 x signal, 1 x CAN ground recommended)
Number of PDOs (CANopen)	16 send and 16 receive process data objects
Additional CANopen Features	Life guarding, node guarding, emergency object, variable mapping, store/restore
Configuration Possibility	Through KS2000 or the controller (service data objects)
Control Voltage Supply	24 V DC (-15 % / +20 %)
Power Supply Connection	Feed: 1 x M8 male socket, 4-pin; Downstream: 1 x M8 female socket, 4-pin
Box Supply Current	45 mA + current consumption of sensors, max. 0.5 A
Electrical Isolation	500 V (control voltage / fieldbus)
I/O Communication Types	Event-driven, cyclic, synchronous, polling
Operating Temperature Range	0 to +55 degC
Storage Temperature Range	-25 to +85 degC
Vibration / Shock Resistance	Conforms to EN 60068-2-6 / EN 60068-2-27
EMC Immunity / Emission	Conforms to EN 61000-6-2 / EN 61000-6-4
Protection Rating	IP65 / IP66 / IP67 (conforms to EN 60529)
Installation Position	Variable
Approvals / Markings	CE, UL
Country of Origin	Germany

Connections / Interfaces

Interface	Function
M12 Plug, 5-pin	CANopen Bus Interface
M8 Male Socket, 4-pin	Power Supply Feed (Control and Load Voltage)
M8 Female Socket, 4-pin	Downstream Power Supply Connection

Installation Guidelines

Ensure the system is completely de-energized before beginning installation or wiring work.
Verify that the exact model code and supply voltages match system requirements.
Mount the Fieldbus Box securely onto a flat machine surface using appropriate hardware in a variable position suitable for the application.
Connect the 24 V DC control voltage supply to the M8 male socket feed.
Connect the shielded copper cable for the CANopen bus to the 5-pin M12 plug interface, ensuring proper grounding of the CAN ground.
Establish signal connections according to the specific peripheral I/O requirements.
Perform a complete inspection of all connections and verify communication parameters before re-energizing the system.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What communication protocol does the BECKHOFF IP3312-B510 use?

The BECKHOFF IP3312-B510 utilizes the CANopen communication protocol, featuring 16 send and 16 receive process data objects as well as support for node guarding and emergency objects.

What is the ingress protection rating of the BECKHOFF IP3312-B510?

The BECKHOFF IP3312-B510 features an IP65, IP66, and IP67 protection rating, making it suitable for harsh industrial environments requiring resistance to dust and moisture.

How is the BECKHOFF IP3312-B510 configured?

The BECKHOFF IP3312-B510 can be configured either through the KS2000 software tool or directly via the controller using service data objects.

What power supply is required for the BECKHOFF IP3312-B510?

The BECKHOFF IP3312-B510 requires a 24 V DC control voltage supply with a tolerance of -15 percent to +20 percent, connected via an M8 male socket.

What data transfer rates does the bus interface support?

The BECKHOFF IP3312-B510 supports automatic detection of data transfer rates ranging from 10 kbaud up to 1 Mbaud.
