Beckhoff KL9520 AS-Interface Potential Feed Terminal

SKU KL9520

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: KL9520
Origin Germany
Product Type: Potential Feed Terminals
Payment: T/T, Western Union
Weight: 2.0 kg
Dimensions: 12 mm x 100 mm x 68 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The KL9520 is an AS-Interface potential feed terminal with an integrated filter, engineered for seamless integration into the Beckhoff Bus Terminal system. This terminal is designed to provide potential distribution for AS-Interface systems, supporting input and output voltages of up to 35 V DC with a maximum current load of 2 A. Housed in a compact terminal design, the KL9520 facilitates efficient power distribution within DIN rail-mounted automation architectures.

Features

Integrated filter for AS-Interface potential feed
Supports input and output voltages up to 35 V DC
Maximum current load of 2 A
Maintenance-free: No address or configuration settings required
Compact housing compatible with standard Bus Terminal systems
DIN rail mounting with double slot and key connection for robust side-by-side assembly

Technical Specifications

Feature	Specification
Manufacturer	Beckhoff
Product Type	AS-Interface Potential Feed Terminal
Voltage Range	Up to 35 V DC (Input/Output)
Max. Current Load	2 A
Operating Temperature	0…+55 degC
Storage Temperature	-25…+85 degC
Protection Rating	IP20
Dimensions	12 mm x 100 mm x 68 mm
Weight	Approx. 90 g
Mounting	35 mm DIN rail (EN 60715)
Approvals	CE

Installation Guidelines

Mounting: Secure the terminal onto a 35 mm DIN rail; utilize the integrated lock for stability.
Side-by-Side Mounting: Ensure proper connection using the double slot and key mechanism for reliable power contact alignment.
Wiring: Supports solid (s), stranded (st), and ferrule (f) conductors. Use a screwdriver for spring-actuated terminal connections.
Connection Cross-sections:
- Solid/Stranded: 0.08…2.5 mm² (AWG 28…14)
- With Ferrule: 0.14…1.5 mm² (AWG 26…16)
Stripping Length: 8…9 mm.
Maintenance: Ensure the installation environment maintains humidity levels below 95% (non-condensing) and adheres to EN 60068 standards for vibration/shock.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the KL9520?

The KL9520 is a potential feed terminal with an integrated filter designed for AS-Interface systems.

What is the maximum voltage supported by this terminal?

The terminal supports input and output voltages up to 35 V DC.

Does the KL9520 require address configuration?

No, the terminal does not require any address or configuration settings.

What is the maximum current load for the power contacts?

The current load for power contacts is 10 A, while the terminal itself supports a maximum load of 2 A.
