Processing analog standard signals in the range from 0 to 20 mA, the BECKHOFF KS3012 Bus Terminal provides reliable, galvanically isolated data acquisition directly to the K-bus system. Featuring two differential inputs with a 12-bit resolution, this unit offers high-accuracy signal conversion within approximately 2 ms. The pluggable wiring level characteristic of the KS series allows system operators to quickly exchange the terminal block during maintenance without disturbing existing field wiring connections.
This module operates with an internal resistance of 80 Ohms combined with a diode voltage of 0.7 V, supporting a maximum common-mode voltage of 35 V. It is designed to mount seamlessly onto standard 35 mm DIN rails, offering space-saving integration inside compact control cabinets.
| Manufacturer | BECKHOFF |
| Part Number / Model | KS3012 |
| Number of Inputs | 2 |
| Signal Current | 0 to 20 mA |
| Technology | Differential input |
| Internal Resistance | 80 Ohm + diode voltage 0.7 V |
| Common-Mode Voltage (Ucm) | Max. 35 V |
| Conversion Time | ~2 ms |
| Resolution | 12 bit |
| Measuring Error | < +/-0.3 % (relative to full scale value) |
| Surge Voltage Resistance | 35 V DC |
| Electrical Isolation | 500 V (K-bus/signal voltage) |
| Current Consumption (K-bus) | Typ. 60 mA |
| Current Consumption (Power Contacts) | None (no power contacts) |
| Process Image Bit Width | Input: 2 x 16-bit data (2 x 8-bit control/status optional) |
| Operating Temperature | -25 to +60 degC |
| Storage Temperature | -40 to +85 degC |
| Relative Humidity | 95 %, no condensation |
| Vibration / Shock Resistance | Conforms to EN 60068-2-6 / EN 60068-2-27 |
| EMC Immunity / Emission | Conforms to EN 61000-6-2 / EN 61000-6-4 |
| Protection Rating | IP20 |
| Dimensions (L x W x H) | 6.8 cm x 1.2 cm x 10.0 cm |
| Weight | 0.07 kg |
| Connection Parameter | Specification |
|---|---|
| Wiring Mechanism | Spring actuation by screwdriver |
| Solid Conductor Cross-Section (s) | 0.08 to 1.5 mm² (AWG 28 to 16) |
| Stranded Conductor Cross-Section (st) | 0.08 to 1.5 mm² (AWG 28 to 16) |
| Flexible Conductor Cross-Section (f) | 0.14 to 1.5 mm² (AWG 26 to 16) |
| Stripping Length | 9 to 10 mm |
| Power Contact Current Load (Imax) | 10 A |
Mount the KS3012 terminal directly onto a standard 35 mm DIN rail (EN 60715) ensuring the locking mechanism clicks securely. When wiring, insert a small flat-head screwdriver into the spring release slot to open the clamp, insert the stripped wire (9 to 10 mm), and remove the tool to secure the connection. Ensure signal wiring is physically separated from high-power distribution lines to minimize electromagnetic interference.
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: KS3012
Country of origin:Germany
Product Type: Bus Terminals
Payment: T/T, Western Union
Weight: 70g
Dimensions: 6.8 cm x 1.2 cm x 10.0 cm
Shipping port: Xiamen
Warranty: 12 months
