Beckhoff ZB7100-1000 EtherCAT P Cable

SKU ZB7100-1000

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: ZB7100-1000
  • Origin Germany
  • Product Type: Industrial Ethernet Cables
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Dimensions: 1 x 4 x 0.34 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

EtherCAT P Industrial Ethernet Cables
Quantità
Call sales Contact

Product Description

Description

Designed to support demanding modern automation architectures, the ZB7100-1000 functions as a highly durable, raw EtherCAT P cable engineered to transmit both deterministic communication signals and auxiliary power lines in a single integrated run. This hybrid cabling approach streamlines field level wiring by bundling high-performance Ethernet data conductors with dedicated power cores, reducing overall installation time and physical space requirements in cable trays.

Constructed with a robust polyurethane (PUR) outer jacket, this raw cable is highly optimized for dynamic industrial environments, including continuous-motion drag chain systems. The composition provides high resistance against mechanical stress, abrasion, and typical industrial oils or chemicals, ensuring long-term signal integrity and system uptime in demanding multi-axis machinery setups.

Features

  • Hybrid design combining EtherCAT communication and power supply conductors within one raw cable envelope.
  • Highly flexible outer PUR (polyurethane) jacket suitable for continuous dynamic movement in energy drag chains.
  • Engineered without an overall shield, optimizing diameter and flexibility for applications where space and bending radiuses are critical.
  • High-contrast black jacket with a distinct red stripe to ensure fast identification and trace-routing in complex control cabinets.

Applications

  • Industrial robotics and multi-axis articulation cells.
  • Decentralized fieldbus installations and automated logistics systems.
  • Packaging, food-processing, and material handling machinery.
  • Machine tool manufacturing requiring energy chains.

Technical Specifications

Manufacturer Beckhoff
Part Number / Model ZB7100-1000
Cable Type EtherCAT P raw cable
Ethernet Cross-Section 1 x 4 x 0.34 mm² (AWG 22)
Power Cross-Section 2 x 0.75 mm² (approx. AWG 18)
Overall Shielding No overall shield
Dynamic Suitability Drag-chain suitable
Jacket Material PUR (polyurethane)
Outer Cable Diameter 9.0 mm ± 0.2 mm (0.3543" ± 0.0079")
Jacket Color Black (similar to RAL 9005) with red stripe (similar to RAL 3020)
Shipping Weight 2.0 kg

Connections and Interfaces

Conductor Group Cross-Sectional Area Function Type
Ethernet cores (4 cores) 0.34 mm² (AWG 22) High-speed EtherCAT communication
Power cores (2 cores) 0.75 mm² (approx. AWG 18) Auxiliary voltage supply lines (Us/Up)

Installation Guidelines

  • Bending Radius: When installing in drag chains, maintain the minimum bending radius recommended for flexible applications to prevent internal conductor fatigue.
  • Tension Management: Avoid exceeding the maximum tensile limits during cable routing and installation. Cables should be laid without twists or kinks.
  • Chain Layout: Ensure proper weight distribution and spacing clearance inside the energy chain, avoiding placement directly adjacent to high-voltage power cables without adequate shielding or separation.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the Beckhoff ZB7100-1000 cable?
The ZB7100-1000 is a raw EtherCAT P hybrid cable designed to transmit both high-speed EtherCAT data signals and auxiliary power supply lines within a single cable run.
Can this cable be used in moving machine parts and energy chains?
Yes, the ZB7100-1000 features a highly flexible PUR jacket and internal configuration designed specifically for dynamic, drag-chain applications.
Does the ZB7100-1000 feature an overall shield?
No, this specific model (ZB7100-1000) is designed without an overall shield, optimizing flexibility and reducing diameter for specific system topologies.
What are the cross-sections of the internal conductors?
The cable contains an Ethernet section of 1 x 4 x 0.34 mm² (AWG 22) and a power section of 2 x 0.75 mm² (approx. AWG 18).
