Bently Nevada 133434-01 3500/50M Tachometer I/O Module

SKU 133434-01

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 133434-01
  • Origin United States
  • Product Type: Tachometer I/O Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.4 kg
  • Dimensions: 241.3 mm x 24.4 mm x 99.1 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3500/50M I/O Modules

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 133434-01 3500/50M Tachometer I/O Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Bently Nevada 133434-01 is a 3500/50M Tachometer I/O Module designed for external terminations within the Bently Nevada 3500 Monitoring System. The 133434-01 interfaces with the 3500/50M Tachometer main board to process input signals from up to two proximity probes or magnetic pickups to determine shaft rotative speed, rotor acceleration, or rotor direction. It routes transducer inputs, buffered transducer signals, and proportional 4 to 20 mA recorder outputs to External Termination (ET) Blocks via dedicated cabling.

Features

  • External Termination Interface: Connects to external termination blocks via dedicated signal cables.
  • Dual-Channel Support: Handles inputs from up to two proximity transducers or magnetic pickups.
  • Proportional Analog Outputs: Provides individual +4 to +20 mA recorder outputs proportional to full-scale speed or acceleration ranges.
  • Buffered Signal Routing: Routes buffered transducer signals to external termination points.
  • Rear-Slot Installation: Mounts in 1 full-height rear slot of the 3500 system rack.

Applications

  • Turbomachinery rotative speed monitoring
  • Rotor acceleration and speed band measurement
  • Reverse rotation detection and zero speed notification
  • Industrial machinery monitoring requiring external terminal wiring configurations

Ordering Information

Part Number / Option Description
133434-01 I/O Module with External Terminations
3500/50-02-BB 3500/50M Tachometer Module with I/O Module with External Terminations
125808-05 Tachometer ET Block (Euro Style connectors)
128015-05 Tachometer ET Block (Terminal Strip connectors)
128702-01 Recorder ET Block (Euro Style connectors)
128710-01 Recorder ET Block (Terminal Strip connectors)
135101-AAAA-BB 3500 Tachometer Signal to ET Block Cable
129529-AAAA-BB 3500 Recorder Output to ET Block Cable

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada (Baker Hughes)
Part Number 133434-01
Module Type Tachometer I/O Module with External Terminations
Rack Space Requirement 1 full-height rear slot
Dimensions (H x W x D) 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in)
Weight 0.20 kg (0.44 lb)
Input Signal Range +10.0 V to -24.0 V
Input Impedance 20 k Ohm (standard)
Transducer Power Supply 24 Vdc, 40 mA maximum per channel
Recorder Output +4 to +20 mA (Load resistance 0 to 600 Ohm)

Installation Guidelines

  • Mount the I/O module in 1 full-height rear slot corresponding directly to the slot containing the 3500/50M Tachometer Monitor Module on the front of the rack.
  • When using External Termination I/O modules, External Termination Blocks and signal cables must be ordered separately.
  • External Termination Blocks cannot be used with Internal Termination I/O modules.
  • Use Bussed External Termination Blocks with TMR I/O modules only.

Compliance and Certifications

  • EMC: European Community Directive 2014/30/EU; Standards: EN 61000-6-2, EN 61000-6-4
  • Electrical Safety: European Community Directive 2014/35/EU; Standard: EN 61010-1
  • RoHS: European Community Directive 2011/65/EU
  • China RoHS: Cables EFUP designation of 15 years per SJ/T 11364-2024
  • Maritime: DNV GL rules for classification; ABS Rules for Condition of Classification
